Модуль видеокамеры 4K с датчиком IMX415 30 кадров в секунду для онлайн-конференций |
- Категории: Tablets >>>
- Поставщик: MIDAS,TOUCH,SOLUTIONS,INC.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Overview of 4K USB-kameramodul
【ULTRA HD 4K 2160P USB CAMERA 】 4K High resolution autofocus usb webcam, max resolution is 3840×2160@30fps. It is exactly double the horizontal and vertical resolution of 1080p for a total of 4 times as many pixels. Equipped with high-tech optics and lenses, an 8-megapixel webcam delivers razor-sharp videos. Record professional-quality video in stunning 4K Ultra HD, Clearly sees all of the details and colors that pop out on screen.
【 ADVANCED SONY IMX415 SENSOR】 USB camera adopt to advance sony IMX415 image sensor, Max resolution:3840*2160P, High frame rate 2160P@30fps, Compression format: MJPEG / YUV2(YUYV).which provides you the excellent quality video. It is specially designed and optimized for professional video production, surveillance system manufacturing, industrial vision.
【88.2 DEGREE WIDE ANGLE LENS 】 Wide-angle 88.2-degree USB cameras can meet most capturing and video requirements, 4k high-resolution USB Camera with Sony IMX415 image sensor. Lower Color reproduction deviation produces sharp images and accurate information, a Super small and thin profile for embedded applications. Good for all kinds of machine vision, Wide application for 3D scanner, VR camera, electronic microscope, medical machine, automated image acquisition system.
【 HIGH-SPEED USB2.0 PLUG & PLAY 】 USB power cable, no additional driver required. You just need to plug the USB camera into your device’s USB port, then you can use video software such as video conference, machine vision,3D scanner VR, USB2.0 plug and play for MAC Linux Windows Raspberry Pi, PC Laptop Notebook for Video Conference Live Steaming
【SUPERIOR COMPATIBILITY USB WEBCAM MODULE 】 4K ULTRA HD USB camera module works with most video apps including MAC Window Linux Raspberry Pi and more. Compatible with Windows 2000/XP/7/8/10 and above, Android 5.0 or higher version, Mac OS, and Chrome OS.
【 ADVANCED SONY IMX415 SENSOR】 USB camera adopt to advance sony IMX415 image sensor, Max resolution:3840*2160P, High frame rate 2160P@30fps, Compression format: MJPEG / YUV2(YUYV).which provides you the excellent quality video. It is specially designed and optimized for professional video production, surveillance system manufacturing, industrial vision.
【88.2 DEGREE WIDE ANGLE LENS 】 Wide-angle 88.2-degree USB cameras can meet most capturing and video requirements, 4k high-resolution USB Camera with Sony IMX415 image sensor. Lower Color reproduction deviation produces sharp images and accurate information, a Super small and thin profile for embedded applications. Good for all kinds of machine vision, Wide application for 3D scanner, VR camera, electronic microscope, medical machine, automated image acquisition system.
【 HIGH-SPEED USB2.0 PLUG & PLAY 】 USB power cable, no additional driver required. You just need to plug the USB camera into your device’s USB port, then you can use video software such as video conference, machine vision,3D scanner VR, USB2.0 plug and play for MAC Linux Windows Raspberry Pi, PC Laptop Notebook for Video Conference Live Steaming
【SUPERIOR COMPATIBILITY USB WEBCAM MODULE 】 4K ULTRA HD USB camera module works with most video apps including MAC Window Linux Raspberry Pi and more. Compatible with Windows 2000/XP/7/8/10 and above, Android 5.0 or higher version, Mac OS, and Chrome OS.
I/O ports (Front) | ||
Size(LWH/mm) | 38.0 x 38.0 x 32.0±0.2 mm (include PCB Thickeness) | |
PCB Thickeness | 1.0 mm | |
Output Interface | USB 3.0 | |
Image/Video Format | 1x Power On/Off Button | |
HD | 1280x720 | |
FHD | 1920x1080 | |
2K | 2048x1536 | |
2.7K | 2688x1512 | |
QSXGA | 2592x1944 | |
UHD | 3840x2160 | |
Frame Rate | 8.29 M – 30FPS | |
Video Class Compliant | YES | |
LED Indicate | N/A | |
Operating Temperature | -10℃ to +65℃ | |
Power Consumption | ||||||
Min | Type | Max | ||||
Input Supply Voltage | 4.85V | 5V | 5.25V | |||
Un-configured Current | - | - | - | |||
Operating Current | - | - | - | |||
Suspend Current | - | - | - | |||
Backend IC Specification | ||
Type | AIT8589D Backend IC with USB3.0 interface | |
Compatibility | USB Video class Compliant, Microsoft WHQL Certified | |
Support Sensor Size | Support Most popular CMOS sensors | |
OS Supported | Win10, Linux, Android | |
Sensor Specification | ||
Optical format | SONY IMX415 1/2.5-inch 8M CMOS Sensor | |
Active resolution | 3840H×2160V | |
Unit pixel size | 1.62μm x 1.62μm | |
0°C to 40°C (with standard HDD/SSD/SATA‐Slim/DRAM) | ||
Lens Specification | ||
F/No. | 2.2 土 5% | |
Field of View | 120° (Diagonal) 112(H) 75(V) | |
Focus Distance | 50cm | |
Company Profile
About Us
We are committed to being your trustworthy partner in supplying quality fingerprint, IoT, tablet and embedded PC systems. With extensive computing experience, a talented R&D team and an exceptional service quality model, we leverage on these capabilities to deliver products that surpass customer expectations. These core strengths have enabled our customers to come up with impactful solutions.
Our Team
Exhibition
Winning experience
Oversea Extend
Certificates
FAQ
Q1:Why we should choose you?
1). Reilable-we provided the quality products to meet your requriement.
2). Professional: Our expert can fully support your special requests.
3). Service: Our team is with PMP certificated so can well control the project schedule and cost for you.
Q2:How about the shipping cost?
A2:For the sample, we provide the DHL/Fedex/UPS. For the large quantity, we can provide the forwarder for you.
Q3:How about the price?
A3:The price depends on the quantity you want.Finally quotation according to your specifications.
Q4:How about the sample lead time? What is the payment?
A4:The lead time for the sample is about 3-5 working days after receipt of your payment.We accept the sample amount less than USD$1000 pay by PayPal.
Q5: Can you OEM/ODM camera module?
A5: Yes, we can offer OEM camera modules according to customer's different requirement.
Q6: Can you provide SDK for secondary development?
A6: Yes, We can offer Linux, Windows, Android SDK.
Q7: What's your USB cameras' production cycle?
A6: We can supply the camera module for a long time. as long as customers need it.
Q8: Are you manufacturer?
A8: Yes, we are designer and manufacturer for USB camera module
Q9: Does the camera support Raspberry Pi? If support Linux system?
A9: Yes, all our USB cameras support Raspberry Pi system and Linux system.
Q10: Does the camera support OTG?
A10: Most of our USB cameras support OTG function.
A5: Yes, we can offer OEM camera modules according to customer's different requirement.
Q6: Can you provide SDK for secondary development?
A6: Yes, We can offer Linux, Windows, Android SDK.
Q7: What's your USB cameras' production cycle?
A6: We can supply the camera module for a long time. as long as customers need it.
Q8: Are you manufacturer?
A8: Yes, we are designer and manufacturer for USB camera module
Q9: Does the camera support Raspberry Pi? If support Linux system?
A9: Yes, all our USB cameras support Raspberry Pi system and Linux system.
Q10: Does the camera support OTG?
A10: Most of our USB cameras support OTG function.
