Биометрический емкостный датчик отпечатков пальцев
- Категории: Other Access Control Products >>>
- Поставщик: MIDAS,TOUCH,SOLUTIONS,INC.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Features
* Outlook is square
* Spatial resolution 508 DPI
* 2D sensor array of 160×160 pixels
* Sensing area 8 mm x 8 mm
* SIP package size：12.2mm x 12.2mm x 0.45mm
* Built-in 8-bit ADC for digitizing the image
* The built-in programmable voltage reference
* High-speed SPI interface
* 0.8 sec readout time
* Support 160-byte on-chip data FIFO
* 65Volt ~ 3.6Volt for I/O communication
* Advanced SiP package to reduce the size and provide better water and dust protection
* Windowing function to crop the smaller image
* Finger detection function to detect the finger on the sensor
* Interrupt pin to wake up host when the finger on the sensor at standby mode
* 1mA power consumption at standby mode
* 1uA power consumption at power-down mode
* Spatial resolution 508 DPI
* 2D sensor array of 160×160 pixels
* Sensing area 8 mm x 8 mm
* SIP package size：12.2mm x 12.2mm x 0.45mm
* Built-in 8-bit ADC for digitizing the image
* The built-in programmable voltage reference
* High-speed SPI interface
* 0.8 sec readout time
* Support 160-byte on-chip data FIFO
* 65Volt ~ 3.6Volt for I/O communication
* Advanced SiP package to reduce the size and provide better water and dust protection
* Windowing function to crop the smaller image
* Finger detection function to detect the finger on the sensor
* Interrupt pin to wake up host when the finger on the sensor at standby mode
* 1mA power consumption at standby mode
* 1uA power consumption at power-down mode
Overview
The MFC-2160 circular fingerprint sensor is based on capacitive-touched technology with a hardened surface and enhanced ESD strength. The built-in analog and digital circuits could minimize the number of external components, and provide easy-to-use standard SPI interface to microprocessors.
The operation of the MFC-2160 circular capacitive fingerprint sensor is as following, a fingerprint image captured by the pixel array, delivering fingerprint ridge or valley signals to A/D converter and digital processor, then to the serial peripheral
interface for data-reading. The image quality of MFC-2160 circular capacitive fingerprint sensor can be adjusted by setting gain,offset and reference voltage parameters internally. In addition, the internal operations and interface speed can also be configured to meet various finger conditions.
MFC-2160 circular capacitive fingerprint sensor also has a finger detection function and windowing function for different
applications such as the fingerprint padlock, fingerprint wearable devices, and fingerprint access control.
This fingerprint sensor chip is 100% made in Taiwan and the quality is super reliable. We also support the algorithm with extra MCU
The operation of the MFC-2160 circular capacitive fingerprint sensor is as following, a fingerprint image captured by the pixel array, delivering fingerprint ridge or valley signals to A/D converter and digital processor, then to the serial peripheral
interface for data-reading. The image quality of MFC-2160 circular capacitive fingerprint sensor can be adjusted by setting gain,offset and reference voltage parameters internally. In addition, the internal operations and interface speed can also be configured to meet various finger conditions.
MFC-2160 circular capacitive fingerprint sensor also has a finger detection function and windowing function for different
applications such as the fingerprint padlock, fingerprint wearable devices, and fingerprint access control.
This fingerprint sensor chip is 100% made in Taiwan and the quality is super reliable. We also support the algorithm with extra MCU
Fingerprint Recognition Algorithm Support
* Good adaptability to dry, wet, or fuzzy fingerprint
* Repair the fractured fingerprints automatically
* Great anti-deformation ability
* Supporting 360 °Authentication
* Self-learning during usage
* Fingerprint Template Size < 1KB
* Verification speed < 700 ms
* Repair the fractured fingerprints automatically
* Great anti-deformation ability
* Supporting 360 °Authentication
* Self-learning during usage
* Fingerprint Template Size < 1KB
* Verification speed < 700 ms
MFC-2160/Q | MFC-1160 | MFC-1082 | |
Sensor | 160*160 Pixel | 160*160 Pixel | 82*62Pixel |
Cost/Performance | High-end | Medium | Low cost |
Algorithm | +MCU (0.75mm) | +MCU (0.75mm) | +MCU |
Function | parts | parts | parts |
Application | laptop, tablet, lock | windows laptop, tablet, lock | handheld device, tablet, lock |
Note: All specifications are subject to change without furthur notice.
Applications
* Biometric authentication on card/Smart Card/Cold Wallet
* Identification Card/Driver License Card/ID card
* External fingerprint reader/fingerprint scanner
* Fingerprint SSD/Fingerprint HD/fingerprint Keyboard
* Personal handheld devices (Mobile/Tablet/Notebook)
* Fingerprint padlock, fingerprint jewelry box, USB fingerprint reader
* Identification Card/Driver License Card/ID card
* External fingerprint reader/fingerprint scanner
* Fingerprint SSD/Fingerprint HD/fingerprint Keyboard
* Personal handheld devices (Mobile/Tablet/Notebook)
* Fingerprint padlock, fingerprint jewelry box, USB fingerprint reader
Ordering Information | ||||||||
MFC-2160 | 160*160 pixel round capacitive fingerprint sensor with IP67 | |||||||
Company Profile
Our Advantages
Exhibition
Winning experience
Oversea Extend
Certificates
FAQ
Q1: What is Midas Touch core competence?
Q2: Why we should choose you?
A2:
A2:
● Size: Size is really mater. It will cause the FAR/FRR rate. Please refer the attachment. FRR/FAR: Ours is FRR:1.5% and FAR : 1/100,000. Mobile security level is only 1. Ours is about level 3 to 4. Please refer the following chart. FRR/FAR is lower which is better.
● ESD: most of the sensor in the market is only+-8KV, ours is +-15KV which is standard. https://en.ppt-online.org/14877
● 100% made in Taiwan. Our factory is VIS which invested by TSMC. TSMC provides the chipset to Apple.
● 100% made in Taiwan. Our factory is VIS which invested by TSMC. TSMC provides the chipset to Apple.
Q3: What is Midas Touch sensor advantage?
● Spatial Resolution 508 DPI
● Data Encryption
● Short Read Out Time
● Multiple Options Available in Different Pixel size
● 360 Degree Matching
● Low Power Consumption
● High-Speed SPI Interface
● IP67 Approved
● Spatial Resolution 508 DPI
● Data Encryption
● Short Read Out Time
● Multiple Options Available in Different Pixel size
● 360 Degree Matching
● Low Power Consumption
● High-Speed SPI Interface
● IP67 Approved
Q5:How about the shipping cost?
A5:For the sample, we provide the DHL/Fedex/UPS. For the large quantity, we can provide the
forwarder for you.
A5:For the sample, we provide the DHL/Fedex/UPS. For the large quantity, we can provide the
forwarder for you.
Q6:How about the price?
A6: The price depends on the quantity you want. Finally quotation according to your specifications. Please send the inquiry for the quantity price.
A6: The price depends on the quantity you want. Finally quotation according to your specifications. Please send the inquiry for the quantity price.
Q7:How about the sample lead time? What is the payment?
A7: The lead time for the sample is about 3-5 working days after receipt of your payment. We accept
the sample amount less than USD$1000 pay by PayPal or credit card.
A7: The lead time for the sample is about 3-5 working days after receipt of your payment. We accept
the sample amount less than USD$1000 pay by PayPal or credit card.
