Электрическая гибкая доска FPC для сенсорного

Цена:*

Стоимость в USD (на сегодня):Узнать

Количество:

Electrical Flexible FPC Board For Touch Screen Digitizer

Details Images

Application

Product Description

Item	Description	Cabability
Number of Layer		1~6(Rigid-Flex & Multilayer)
Min. Trace Width Min. Space	Single Side	0.05mm(2 mil)
		Double Side	0.05mm(2 mil)
		Multi-layer	0.05mm(2 mil)
Min. Hole Diameter	CNC Drill	0.1mm(4 mil)
Min. Hole Diameter		Punching	0.5mm(20 mil)
Surface Treatment	Gold Plating	0.025µm-1.25µm(1µ"-50µ")
		Soft ENIG	0.025µm-0.1µm(1µ"-4µ")
		Tin Plating	60µ"~500µ"
Dimension Tolerances	Conductor Width	General±0.03mm, Special±0.02mm
		Accumulated Pitch (Total Length≦30mm)	General±0.05mm, Special±0.03mm
		Outline Dimension	General±0.1mm, Special±0.05mm
		Outline Shift Tolerance	General±0.1mm, Special±0.07mm
		Apply Coverlay Tolerance	General±0.3mm, Special±0.15mm
		Hole Diameter	±0.05mm
		Silkscreen Printing	General±0.5mm, Special±0.3mm
		Stiffener Paste	General±0.5mm, Special±0.2mm
Thickness Tolerances	Silver Paste	5-30µm
		Solder Mask	5-20µm
		ACP Paste	10-30µm
		ZIF Area	General±0.05mm, Special±0.03mm
		FPC Thickness	General±0.05mm, Special±0.03mm
SMT Capability	Connector Min Pitch	Pitch 0.4mm
		Passive Component	201
		IC Bonding Min Pitch	Pitch 40um
		Solder Heat Resistance	300°C / 10 sec
Flammability		UL- 94V-0

For More Products

Company Profile

Product Packaging

FAQ

PRODATA INTERNATIONAL CORP.
4F, NO.43, LN. 3, SEC. 1, ZHONGZHENG E. RD.,
TAMSUI DIST.,NEW TAIPEI CITY 25147, TAIWAN (R.O.C.)
Tel: 886 2 -26251940

Fax:886 2- 26239540
Website: www.prodata.com.tw
Alibaba: prodata.en.alibaba.com
