Features:
•It provides an amazingly clear, fine observations by using Xenon light source.
•-2 °+6° coxial illumination greatly improves the intension and range of red light reflex.
•UV-proof and heat absorption reduces the harm to intraocular tissues and make the patient feel more comfortable.
• Germany imported Schott optics ensure the surgeons a bright, balanced and fine observation.
• Apochromatic technology used in the optical design, ensures coaxial light focus and makes a clearer field of view.
•Lock device under the microscope arm prevents accident from happening.
•Fine focusing knob is under the bottom of assistant binocular. The obervation of the assistant’s microscope can be finely
focused independently from the main microscope, to avoid the different observations from the surgeon.
Eyepiece Magnification | 12.5×/18B |
Objective Lens | f=200 |
Working Distance | 170mm |
Magnification for Main Microscope | 4.6×-27×, motorized and manual control, Continuous Magnification |
Magnification for Assistant Microscope | 6×,10×,16× |
Diameter of Field | φ46mm ~φ8.5mm |
Diopter Adjustment | ±7D |
Pupil Distance | 50mm ~ 75mm (main microscope is 45mm ~ 80mm) |
Maximal Resolution | 126LP/mm |
Focusing Range for Assistant Microscope | ≥30mm |
Illumination Source | 120V/100W Medical Xenon Lamp and 12V/100W Halogen Lamp. Dual-source hand- switched |
Illumination Type | 6°+2°Coaxial illumination, 26°oblique illumination |
Filter | UV-IR Filter, Yellow Spot Protection Filter,Redfree,GG435,GG475 |
Coaxial Illumination | ≤1800001x(xenon); ≥60000lx(Halogen),1-99 level; Foot/Panel operated |
Oblique Illumination | ≤1800001x(xenon); ≥60000lx(Halogen),1-99 level; Foot/Panel operated |
Reaching Radius of Arm | 1230mm |
Adjustable Vertical Range | 925mm ~ 1465mm |
Fine Focusing Speed and Range | ≤2mm/s,≥45mm |
Speed for X/Y and Range | ≤2mm/s,50mm×50mm |
Input Voltage | AC220V±22V/50Hz±1Hz, AC110V±11V/60Hz±1Hz |
Power | 280VA |
Fuse | AC250V T4.0A,AC125V T8.0A |
Electrical Safety Standard | Executive standard:GB9706.1-2007 |
Packing Volume | 0.856m3,5cartons |
Total Weight | 230kg |
Q1. Can I have a sample order?
A:Yes, we welcome sample orders to test and check.
Q2. Are you trading company or manufacturer?
A: We are a manufacturer. Please check Our Company Profile. We have been verified onsite by world-leading inspection company
Q3. What are your trading terms?
A:We usually accept FOB Guangzhou, T/T 30% deposit, and 70% balance before shipment.
Q4. How do you ensure your products quality?
A:Production or inspection report before the goods packing. And we got CE, ISO certification.
Q5. What about your after-sale service?
A:We have a professional team for after-sale service. Our team will follow the order once you ordered.
Q6. What is your warranty policy?
A:1-2years due to different products and lifetime maintaining.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery If you have another question, pls feel free to contact us.
Q8: What's the main product?
A: Our main products include combined tables, auto refractometers,Trial Frame, lens meters, chart projectors,slit lamp,tonometer,Phoropter,view testers,pd meter and other processing equipment, including lens edgers. Our company has passed ISO9001 certification and some of the products have passed CE certification.
