DU/DX Bushing Oil-less Dushing Dry Bearings





What is composite bearing?







Composite dry sliding bearings are primarily used for bearing arrangements where heavy loads have to be supported and where rotational or oscillating movements are relatively slow.







Where to use composite bearing?







• Because of their good sliding properties and compact design, these plain bearings are particularly suitable for bearing arrangements where:


• Maintenance-free operation is a prerequisite


• There is a risk of lubricant starvation


• Lubricants cannot be used or are forbidden


• Space is limited.



 Why choose composite bearing?



• Maintenance-free operation


• No lubrication required (PTFE composite)


• Initial lubrication required (POM composite)


• Minimum wall thickness, minimum space requirements


• Accommodation of heavy loads


• Wide range of temperatures


• Good sliding properties


• Virtually no stick-slip


• High wear resistance


• Less sensitive to edge loading (POM composite)


• No machining required







Which kinds and sizes we have?







The standard range of composite plain bearings is very comprehensive and covers almost every standard size. This range comprises straight and flanged bushings, thrust washers and strips.





• Specifications:

Material	Steel backing	Steel+Sinterd Bronze powder+PTFE+Pb+Polymer
	Bronze backing	Bronze+Sinterd Bronze powder+PTFE+Pb+Polymer
	Stainless steel	S.S.+Sinterd Bronze powder+PTFE+Pb+Polymer
	Stainless steel	Stainless Steel+PTFE +Polymer
	Pb Free(RoHS)	All above types without Pb available
Load capacity	Static load	250N/mm2
	Dynamic load	140 N/mm2
	Oscillating	60 N/mm2
Speed Limit	Oil lubricating	5m/s
	Dry friction	2.5m/s
PV value limit	Oil lubricating	50N/mm2.m/s
	Dry friction	3.6 N/mm2.m/s
Friction coef		0.04¬0.20
Working temperature		-195~+280°C



• Cross of composite



• Sizes List



• Production

• Plant

• Automatic Machines

• Inspection

• Packings:



• Other bushings are available too:

Wrapped bronze bushing / bronze bushing / Bimetal bushing / Solid bronze bushing / sintered bushing / graphite bushing





• Our sliding bearings including:

--SF-1(du) oilless bearing bushing (PTFE Composite)

--SF-2(dx) slide bearing bushing (POM Composite)

--FB090(FB090G) bronze bushing

--FB092 bronze bushing

--JDB,JFB solid graphite lubricating bushing

--JF bi-metal bushing

--FU sintered bronze or iron bushing

--FZ POM/Al/Cu ball cage retainer

--FR metal mesh+PTFE Soft strips

--JGB Graphite bearings







Also we can make customized bushings as per your drawings or samples.
