Product Overview
Sunbun, Your best high Speed & Precision Injection Molding Machine
SK series. From 140T-2800T developed since 2002 years which now have servo motor and variable pump two model.
The most advantance double CPU control technology is adpoted
100 MCAN digital communication is used for controlling machine movement with higher control precision and faster response speed
Equipped with high-end new model servo motor . Featured by high torque . Low noise and longer Durability
High Response closed loop control mode make the system pressure and flow stable and accurate
The corresponding power is outputted according to system load . It's more energy saving . The oil temperature is low .
The use of cooling water is reduced . The services life of hydraulic oil and hydraulic parts is enhanced and repetitive precision
is enhanced
100 MCAN digital communication is used for controlling machine movement with higher control precision and faster response speed
Equipped with high-end new model servo motor . Featured by high torque . Low noise and longer Durability
High Response closed loop control mode make the system pressure and flow stable and accurate
The corresponding power is outputted according to system load . It's more energy saving . The oil temperature is low .
The use of cooling water is reduced . The services life of hydraulic oil and hydraulic parts is enhanced and repetitive precision
is enhanced
FEATURES AT A GLANCE
Item / Type | Unit | SK650 | ||||
Injection Part | ||||||
Screw Diameter | A | B | C | |||
Screw Ratio | L/D | 90 | 100 | 110 | ||
Theoretical Injection Volume | cm³ | 2875 | 3550 | 4295 | ||
Injection Volume （PS） | g | 2616 | 3231 | 3908 | ||
Injection Pressure | Mpa | 169 | 137 | 113 | ||
Injection Stroke | mm | 452 | ||||
Max Rotational Speed Of Screw | r/min | 0-136 | ||||
Clamping Part | ||||||
Clamp Tonnage | KN | 6500 | ||||
Toggle Stroke | mm | 960 | ||||
Tie Bar Distane | mmxmm | 980*870 | ||||
Max mold | mm | 1050 | ||||
Min Mold | mm | 450 | ||||
Ejection Stroke | mm | 210 | ||||
Ejector Force Forward | KN | 166 | ||||
Die Timble Amount | Pcs | 1+20 | ||||
Others | ||||||
System Pressure | Mpa | 17.5 | ||||
Motor Power | KW | 30+37 | ||||
Oil Tank Capacity | L | 850 | ||||
Machine Size | M | 8.9*2.5*3 | ||||
Machine Weight | Ton | 26 | ||||
PRODUCT CONFIGURATION
PACKING & DELIVERY
Company Profile
FAQ
Q1：What is your machine warrenty ?
Q3: How about the quality control in your factory?
A3: We have full set testing control files. Every part testing have full record . Before shipment small machine need shot over 7000 times. and big machine shot for 5000 times
A1： For the whole machine we provide 12 month , For the Pull Rod. We provie 24 month For the Mold Platen we provide 36 month
Q2: Are you provide auxiliary machine for the whole project ?
A2: Yes We provide many brand auxiliary machine also provide turnkey solustation
A3: We have full set testing control files. Every part testing have full record . Before shipment small machine need shot over 7000 times. and big machine shot for 5000 times
Q4: What is your lead time ?
A4: If we have stock we can deliver in 3 days. For normal production we need around 30-60 Days depends on machine tonnage
Q5 : Mold trial will be available in your factory ?
A5： Yes, Customer can send the mold to our factory and test. If clients buy mold together, we will testing and send sample to clients for final confirmation then shipment
Q6 . Do you provide any spare parts with machine?
A6: Yes, We will provide one set standard spare parts to customer including heater ,filter, noozle ,tool box etc
A5： Yes, Customer can send the mold to our factory and test. If clients buy mold together, we will testing and send sample to clients for final confirmation then shipment
Q6 . Do you provide any spare parts with machine?
A6: Yes, We will provide one set standard spare parts to customer including heater ,filter, noozle ,tool box etc
Q7: What about your after sales service
A7: we have many experience technical engineers for oversea service, they would help you install machine and provide basic training.
