Новый Эвакуатор-эвакуатор 10 тонн

Type

Tow Wrecker Truck

LiftArm

Model

TAG5312TQZZ06

Max. Lifting weight(kg)

30000

dimension

10350 *2495*3060

Max. Lifting height(mm)

11500

Track(F/R)(mm)

2022/1830

Max. Lifting angle(°)

50

Warning system

Each side and rear with reflecting mark

Rated pulling force of winch(KN)

150

Chassis Model

ZZ1317N4667C

Turning angle

360

Total weight(kg)

19170

Winch quantity

2

Engine

Drag Arm

Model

WD615.96C

Lifting weight at ground(kg)

20000

Power(kw)

276

Rated lifting weight(kg)

4600

Cylinder number

6

Max. length(mm)

3870

Rate speed(rpm)

2200

Expansion distance(mm)

2090

Displacement(ml)

9726

Front overhang(mm)

1500

Torque(N.m)

1600

Rear overhang(mm)

1675

Tire model

11.00R20,11.00-20/12.00-20,12.00R20

Wheelbase(mm)

1800/4600/1350
