Dimensions and Weight | |
wxdxh | 674x280x1075 mm |
Combustion chamber | 200x110x450 mm |
Flue chamber opening wxdxh | 260x250 mm |
Flue outlet diameter | 80 mm |
Weight | 71 kg |
Pellet hopper size | 17 kg |
Heat Output | |
Heat Efficiency | Min 3.14 kW | Max 7.1 kw |
Room Heating Capacity | 150 m3 |
Fuel Consumption | 0.7/1.49 kg/h |
Type of Fuel | L 30 mm | d 6/3 mm |
Performance | |
Coefficient of Efficiency | 92% |
Flue gas temperature | 136C |
CO emission - nominal power | 0.0159% |
Powder Content | 22.9 mg/Nm3 |
NOx (O2ref=13%) | 91.74 mg/m3 |
Packaging | |
Size | 86 (L) * 56 (W) * 112 (D) cm |
Weight | 108 kg |
Packaging Details | The wooden case protects the product from being damaged during longer distance transportation and it is easy for use by forklift or pallet cart. |
