Product Description
Products Details
Specification
Model | BF4 | BF5 | BF6 | BF6.5 | BFP8 | BF10 |
Pixel pitch | 4-8mm | 5-10mm | 6-6mm | 6.5-6.5mm | 8-8mm | 10-10mm |
Module size (mm) | 480*256 | 480*320 | 480*192 | 481*208 | 480*256 | 480*320 |
Resolution density | 120*32 | 96*32 | 80*32 | 74*32 | 60*32 | 48*32 |
Pixel density (px/㎡) | 31250 | 20000 | 27777 | 23670 | 15625 | 10000 |
Optimal viewing distance | 5～100m | 8～100m | 8～100m | 10-100m | 12-100m | 15～120m |
Transparency | ≤65 % | ≤68% | ≤50% | ≤55% | ≤60% | ≤70% |
Weight | 3.5KG/ ㎡ | 3.5KG/㎡ | 3.5KG/㎡ | 3.5KG/㎡ | 3.5KG/㎡ | 3.5KG/㎡ |
Viewing angle | 160° | 160° | 160° | 160° | 160° | 160° |
Thickness | ≤3 mm | ≤3mm | ≤3mm | ≤3mm | ≤3mm | ≤3mm |
Supply voltage (V) | 3.8-5 | 3.8-5 | 3.8-5 | 3.8-5 | 3.8-5 | 3.8-5 |
Average power | ≤ 3 00w/ ㎡ | ≤300w/㎡ | ≤300w/㎡ | ≤300w/㎡ | ≤300w/㎡ | ≤300w/㎡ |
Max consumption | ≤800w/㎡ | ≤800w/㎡ | ≤800w/㎡ | ≤800w/㎡ | ≤800w/㎡ | ≤800w/㎡ |
Refresh rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
White balance brightness | ≤5000cd/㎡ | ≤5000cd/㎡ | ≤5000cd/㎡ | ≤5000cd/㎡ | ≤5000cd/㎡ | ≤5000cd/㎡ |
Drive mode | still | still | still | still | still | still |
Mean time of failure | ≥6500 | ≥6500 | ≥6500 | ≥6500 | ≥6500 | ≥6500 |
Life | 100000 | 100000 | 100000 | 100000 | 100000 | 100000 |
Waterproof | IP45 | IP45 | IP45 | IP45 | IP45 | IP45 |
Packing & Delivery
LED display is packaged with wooden cases or flight case.
1. Wooden case: covered with eco-friendly wood and aluminum edge, with anti-collision EPE foams inside, protect products from damage during transportation.
2. Flight case: hard outer fireproof frame with inner EVA soft rebound material, with durable wheels at the bottom, convenient and safe moving.
Why Choose Us
Our Advantages
Interaction with Clients
FAQ
Q1. What is the weight?
A: Ultra thin and light, only 3.5kg/㎡.
A: Ultra thin and light, only 3.5kg/㎡.
Q2: How to control the film transparent LED display?
A: We use Novastar control system, supports WIFI/LAN/USB/4G wireless control.
A: We use Novastar control system, supports WIFI/LAN/USB/4G wireless control.
Q3: Can you provide installation structures?
A: It is totally structure-free, no installation structure is needed, it is installed by self-adhesive.
A: It is totally structure-free, no installation structure is needed, it is installed by self-adhesive.
Q4. Do you test all your goods before delivery?
A: Yes, we have 100% test for 72hrs before delivery.
A: Yes, we have 100% test for 72hrs before delivery.
Q5: How long is your warranty?
A: 5 years, we will be responsible for free repairment or replacement for defective parts.
A: 5 years, we will be responsible for free repairment or replacement for defective parts.
Q6: What will you do if we have problems related to installation, configuration and use?
A: Our after-sale service team will solve all the problems, until the screen can work normally.
A: Our after-sale service team will solve all the problems, until the screen can work normally.
Q7. What is your terms of payment?
A: 50% as deposit, 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
A: 50% as deposit, 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q8. What is your terms of delivery?
A: EXW, FOB, CIF, CFR, DDP, DDU, customer specified freight forwarder or negotiable mode of transport.
A: EXW, FOB, CIF, CFR, DDP, DDU, customer specified freight forwarder or negotiable mode of transport.
Q9. What is your delivery time?
A: Generally 15-20 days after receiving the deposit. The specific delivery time depends on the quantity of the order.
A: Generally 15-20 days after receiving the deposit. The specific delivery time depends on the quantity of the order.
