Многофункциональная вертикальная машина для взвешивания упаковочная
- Категории: Industrial Machinery >>>
- Поставщик: Foshan,Chuanglibao,Packaging,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Multifunctional Vertical Weighing Packing Machine Popcorn Packing Machine Packaging Machine For Snacks
Model | CB-520PM | ||||||
Max width of roll film | ≤520mm | ||||||
Bag sizes | L(100-400)mm/W(100-250)mm | ||||||
Packing speed | 5-55bags/min | ||||||
Packing material | OPP/CPP, OPP/PE,PET/PE,PE | ||||||
Consumption | 6-8kgf/cm², 0.15m³/min | ||||||
Power and voltage | AC200V, single phase 50-60Hz, 3.5KW | ||||||
Total weight | 720KG | ||||||
Dimension | L(4105)*W(2457)*H(3750)mm | ||||||
Product Features：
Accurate Temperature Control: The independent temperature control system ensures accurate temperature control, resulting in beautiful and smooth sealing.
Intelligent Control: The equipment uses servo motor film pulling, PLC control, and touch screen control for automatic control, resulting in high reliability, intelligence, speed, and efficiency.
Automatic Adjustment: The double-belt film pulling system and color code control system can be automatically adjusted through the touch screen, simplifying the operation of sealing and incision deviation correction.
Versatile: The touch screen interface stores various packaging process parameters for different products, allowing for easy switching between products without the need for manual adjustment.
Customizable: The equipment can be tailored to meet the specific needs of different food and pharmaceutical products, making it highly adaptable and versatile.
PRODUCT DETAILS
APPLICATIONS
COMPANY INFORMATION
PRODUCTION PROCESS
CERTIFICATE
EXHIBITION & CUSTOMER PHOTOS
PACKAGING & SHIPPING
FAQ
Q1: Are you a factory?
A1: Yes, we established in 1998 as a manufacturing supplier with 25 years experience. We can provide you with professional product packaging solutions.
Q2: What info you need before confirming the machine?
A2: Your product picture, your product size(length,width,height,weight etc.),packing type(Back seal / quad seal / 3-side seal / 4-side seal etc),your product samples(for testing).
Q3: What is the material of contact food/material parts?
A3: The contact food/material parts are made of 304# stainless steel. The machine body can be 304# stainless steel or carbon steel.
Q4: Can this machine make different bag sizes?
A4: One former can make one bag width, and the bag length can be adjustable within a range. It should be ordered an extra former if you want to make the other bag width.
Q5: Does your company accept OEM?
A5: Yes, we have a professional design and technical team to accept customization.
Q6: When you can deliver the machine after the order is placed?
A6: We usually can arrange shipment after 30-40 working days, but it depends on the quantity of the products.
Q7: How about your warranty?
A7: We provide 13 months warranty, starts from the issue date of bill of lading.
Q8: What can you provide after service?
A8: We can provide machine testing video and pictures before delivery, English manual, some free spare parts, installation in clients' factory and technical training.
