1. CVBS & Analog signal testing. 2. Check cable wiremap for RJ45 and BNC cable. 3. Trace Lan coax cables quickly. 4. PTZ control and audio testing. 5. Color bar generating and Captures and analyzes RS 485 controlling data. 6. Video generate and display. Automatically adapts and displays the video format of NTSC/PAL. 7. Supply power for Cameras. 8. Bulit-in 3000 mA Lithuim battery. 9. Language selectable: English & Chinese.
Technical Index
Model
NF-704
LCD Screen
3.5" LCD Screen
Audio signal input
Microphone or other audio devices
Color bar
White, blue, purple, green, yellow, black, red
Baud Rates
2400、4800、9600
Vedio format
NTSC/PAL
Vedio output
CVBS/ Analog signal
protocol
20 kinds:PELCO-D/P,SAMSUNG,ect, customised
Language
Chinese/English
Power
DC5V/1A
Battery
bulit-in 3.7V Li-battery , detachable
Working time
18hs for continous working
Working temperature
- 10℃ + 50℃
working humidity
30%-60%
