Brief introduction of the shaped ultrasound extraction tank:

This shaped ultrasound extraction tank is suitable for medicine, health care products, bio-pharmaceuticals, cosmetics, food and other industries ambient pressure extraction, ultrasonic extraction, essential oils, aromatic oils Extraction, purification and other processes. This ultrasonic ultrasound extraction equipment is very suitable for universities, research institutes and enterprises, laboratories and pharmaceutical research and development departments of many varieties, small batch production use.



Features of shaped ultrasound extraction tank:

The shaped ultrasound extraction tank with high efficiency, this shaped ultrasound extraction tank is latest ultra-compact shaped ultrasonic dynamic extraction unit which developed by our company, this device optimize the product structure based on the traditional multi-extracting machines, extraction tanks, straight and helical cone conical extraction tank,integrated the Shaped ultrasonic device in this device, use the Ultrasonic dynamic loop extraction, extraction, filtration, concentrated under reduced pressure, oil condensate and other production processes to saving raw materials and working hours, work efficiency have been increased by 50% to 100% than the average multi-extraction equipment.



The Raw conversion rate is high, this shaped ultrasound extraction tank utilizes ultrasonic unique physical effects, cavitation can induce plant cell tissue broken or deformed, between solute particle vibration, shock acceleration, sound pressure shear stress strengthened, so that the material forming local points of extreme high temperature and pressure, to promote traditional Chinese medicine into the analysis of the effective , the extraction rate significantly increased up to 30-60% than the traditional process .



Shaped ultrasound extraction is room temperature extraction, the active ingredient of the raw materials is not likely to lose. Meanwhile, Yuda series shaped ultrasonic extraction unit uses a pneumatic agitation, enhanced ultrasound cavitation effect, so that medicines can be fully exposed to titanium ultrasonic probe, accelerated APIs homogeneous precipitation of the active ingredient inside.



Our shaped ultrasound extraction tank with the compact structure, fully exert the features of the Ultrasonic wave. The contact area of materials with ultrasonic is big, and the extraction time is short, ultrasonic herbal extracts are usually 20 to 40 minutes to get the best extraction rate, the extraction time is only 1/5 of the traditional pharmaceutical extraction process .



Shanghai Yuda shaped ultrasound extraction tank adaptability: it’s do not limited to ingredients polarity and molecular size for extract Chinese herbal. It’s applies to the extract of vast majority of Chinese herbal extracts and various ingredients;This device is equipped with water separator and efficient condenser, aroma oils are vegetable oils can be extracted.



Equipment selectable frequency range:15KHz,20KHz,28 KHz,30 KHz,35 KHz,40 KHz,50 KHz,60 KHz,80KHz.



Vacuum concentration equipment: According to the raw materials of customer, the scraper concentrated material, l membrane concentration, falling film concentration, membrane concentration is optional.



Parameters of shaped ultrasound extraction tank :



Model	HJT
Capacity	3L---500L
Maximum heating power	Depending on the model, 3.5kw-30kw
Mixing motor power	Depending on the mode,75w-400kw
High temperature magnetic pump power	Depending on the mode,55w-200kw
Ultrasonic Power	Depending on the mode. 100w--3000kw
Mixing control	0-1500 rev / min, digital, stepless
Temperature Control	Temperature -65 °C, Configurable temperature, thermostat system
Device Control	Digital control machine/ PLC touch screen control
Vacuum	-0.05~ -0.08
Use solvent	Water, ethanol, and petroleum ether
Equipment Material	SUS304/SUS316L
Vacuum concentration system	Vacuum concentration, condensation, cooling, water separator
Material handling capacity	Depending on the model, 1.2 - 300 kg / hr range
Dimension	1600mm*850mm*1800mm









Thank you for your interest about our shaped ultrasound extraction tank !
