Guangzhou Hiwell Audio Equipment Factory
--Professional audio woofers, drivers and custom designs.
Model: SW18020/ professional loudspeaker 18"
Features:
8 ohm 99.3mm/4 inch Voice coil High Tempreture resistance
97 dB SPL ,600 Watts RMS
High Ferrite magnet grade
Special paper cone coating for better sound and water against.
| Specifications | |
| Nominal Diameter | 460 mm |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 7.0 Ω |
| Power handling | |
| (50-500Hz) | |
| Nominall | 600 W |
| Continuous Program | 1200 W |
| Sensitivity (1W/1m)3 | 97 dB |
| Frequency Range | 35-2000 Hz |
| Voice Coil Diameter | 99.3 mm |
| Winding Material | Copper |
| Former Marerial | Kapton |
| Winding Depth | 23 mm |
| Magnetic Gap Depth | 12 mm |
| Flux density | 1.1 T |
| Thiele-Small parameters4 | |
| Fs | 35 Hz |
| Re | 5 Ω |
| Qes | 0.54 |
| Qms | 14.1 |
| Qts | 0.52 |
| Vas | 410 L |
| η0 | 2.30% |
| X max | 8.5 mm |
| X mech | 21.5 mm |
| Mms | 135 gr |
| BL | 16.5 N/A |
| Le | 1.7 mH |
| Mounting and Shipping Information | |
| Blot Circle Diameter | 435 mm |
| Overall Diameter | 460 mm |
| Baffie Cutout Diameter | 417 mm |
| Depth | 200 mm |
| Flang and Gasket Tickness | 20 mm |
| Net Weight | 12.9 kg |
| Shipping Weight | 13.9 kg |
| Shipping BOX | 470×470×210 mm |
Packaging & Shipping
Package way:
Shipping:
1. BY SEA; 2. BY AIR
FAQ
1. Can i have bigger voice coil and more power subwoofer?
--Yes, no problem. Please kindly check the list of subwoofer below:
Just Pick one and BUY!
