Lx-60 мебель покрасочная камера для камеры окрашивания распылением (muebles де cabina de

Lx-60 мебель покрасочная камера для камеры окрашивания распылением (muebles де cabina de

Цена:382 551,00 ₽ - 765 102,00 ₽*

Стоимость в USD (на сегодня):Узнать

Количество:

Features:

1. Unique big area air filtering system, filtering rate reach 98%

2. Water curtain filtering, eco-friendly dust disposal

3. Good quality with CE and one year’s guarantee.

4. Carbon fiber far-infrared heater

Specification of furniture spray booth:

Dust Free Painting Room

Dimension of Painting Room (m): 5(L)*5(W)*3(H)

Cabin system	Wallboard	50mm EPS colorful steel skin panel, steel 0.4mm thick,12kg/cbm and flame-resisting EPS, tongue groove style, compound construction, anti-flame and heat-insulation.
	Working door	Two folds of door, 2000mm*2000mm, with clear tempered glass.
	Sliding door	One sliding door, 2000mm2000mm, connected paint booth with drying booth. The finished products could be moved into the drying room through this door.*
Circulation system	Fan	Low noisy and large air volume fans introduced from Siemens technology. Air Capacity:18000m3/h, Air speed 0.45 m/s , Power 2x3Kw.
Purification system	Dual filtering structure, the primary filter can capture granules larger than 10μm. Ceiling filter capture granules bigger than 5μm. Its filtering rate reaches 98%.
Lighting system	36x 36w lamps, explosion-proof, on the ceiling sides. Power: 1.296Kw
Control system	Spraying/baking switch, lighting switch, emergency stop etc. Delixi electrical components, Automatic constant temperature, leakage protection
Water Curtain	Materials: Stainless Steel , Size: 3m(L)0.6m(W)1.8m(H), with a high quality dump 750W
Basement	40mm*3mm flat iron,12#channel steel
Power	220V/50Hz & 380V/50Hz

Dust Free Drying Room

Dimension of Drying Room (m): 15(L)*5(W)*3(H)

Cabin system	Wallboard	50mm EPS colorful steel skin panel, steel 0.4mm thick,12kg/cbm and flame-resisting EPS, tongue groove style, compound construction, anti-flame and heat-insulation.
	Working door	One set of door, 2000mm*2000mm, with clear tempered glass.
Purification system	Dual filtering structure, the primary filter can capture granules larger than 10μm. Ceiling filter capture granules bigger than 5μm. Its filtering rate reaches 98%.
Heating system	Carbon tube heater, 1kw per pcs, explosion-proof, service time≥8000hours, Stainless reflector. Power:
Lighting system	36w lamps, explosion-proof, on the ceiling sides.
Power	220V/50Hz & 380V/50Hz

Remark: A:The doors in the spray-baking room are sliding doors.

B:Glass of doors is tempered glass.

C: Guranteed for one year.

D: Colors of the wall panels could be choice,red/blue/white/orange.

CE certificate
