Wuzheng WAW 4x2 5 тонный легкий грузовик с хорошим качеством

Vehicle brand

WAW

Truck Type

LIGHT TRUCK

Vehicle model

FD1060P10K-9

Fuel type

Diesel

Cabin

one and a half row(1800mm)

Whole vehicle main dimensions

Overall dimensions (LxWxH)mm

6980×2190×2290

Dimensions of the cargo body (LxWxH)mm

4660×2000×500

Driving type

4×2

Wheel base (mm)

3800

Wheel track (front/rear)(mm)

1564/1550

Min. ground clearance (mm)

213

Weight data

Curb weight (kg)

3530

Rated payload(kg)

6000

Persons in cab

3

Gross vehicle weight(kg)

9725

Whole vehicle main performance

Max. speed(km/h)

86

Max. slope of climb(%)

25

Min. turning radius(m)

8

Engine

Model

FAW4102

Type

Four-cylinder, in-line,water cooling, DI, diesel engine

Displacement(L)

3.857

Rated power(kw)

70.6/3200

Max torque (N.m/rpm)

245/2000-2200

Gearbox

Model

530H

Clutch

Type

Single disc

Rear axle

1069Hydraulic brake, ratio6.142

Steering gear

Power steering

Brake system

Service brake

Air brake

Parking brake

Air-brake brake

Auxiliary brake

exhaust brake

Wheels and tyre size

7.50-16

Electric device

Rated voltage

24V

Battery

6-QW-100MF
