Hot sale hydraulic full automatic paper cup plate making machine



Application:

This equipment incorporates plate-washing ,plate-solarizing,glutiosity-free and plate-drying ,In addition ,It adopts lower brush to wash plate rotatablely .with high precision on plate-making and convenient operation .It is an ideal equipment for making flexible printing plate

Technical Parameters:

1.It is made of stainless steel, featuring in durability and won’t get rusty.

2.Opted imported Philip specific printer lamp, Philip rectifier(frequency transforming  type is good for registering).

3.Imported slow reflective violet suction membrane(Japan Toyo)

4.Computer controller enables it to be easily operated.

5.Adopted American digital integrated thermo sensor.

6.Adopted American thermo sensor.

7.Japanese Panasonic or oriental printing plate washer, Japanese ORIX constant dry oven, featuring in strong wind.

8.Adopted Philip specific UVC light source for removing the sticking sheet.

9.Integrated exposure, washing printing plate and removing sheet, it is a good

equipment for making soft printing plates.

Model	Printer area	Machine dimension: w*d*h	power	Plate thickness make	Wooden case dimension w*d*h	Wooden case weight	FOB china mainland port
SJ-400	430*320mm	710*610*1050mm	2.2kw	1-7mm	780*670*1270mm	120kg	2000USD
SJ-600	600*400mm	860*710*1050mm	2.3kw	1-7mm	970*770*1270mm	150kg	2500USD
SJ-800	800*600mm	1090*910*1150mm	3.5kw	1-7mm	1200*980*1440mm	220kg	4500USD
SJ-900	900*600mm	1190*910*1150mm	3.7kw	1-7mm	1300*980*1440mm	260kg	4900USD
SJ-1000	1000*600mm	1290*910*1150mm	3.8kw	1-7mm	1400*980*1440mm	300kg	5400USD
SJ-1200	1200*600mm	1490*910*1190mm	3.9kw	1-7mm	1600*980*1480mm	360kg	5800USD
SJ-1200*900	1200*900mm	1490*1210*1190mm	4.2kw	1-7mm	1600*1330*1480mm	400kg	6800USD
SJ-1200*1000	1200*1000mm	1490*1310*1190mm	4.5kw	1-7mm	1600*1430*1480mm	460kg	7200USD
