Product Description
Wholesale portable galvanized horse stable panel
A stable is a building in which livestock, especially horses, are kept. It most commonly means a building that is divided into separate stalls for individual animals.
Stables can range widely in size, from a small building housing one or two animals to facilities at agricultural shows or race tracks that can house hundreds of animals.
PE cloth can be white or blue, it can be changed if broken. horse kick can't damage the cloth but if sharp point or edge maybemake the cloth broken.
Stables can range widely in size, from a small building housing one or two animals to facilities at agricultural shows or race tracks that can house hundreds of animals.
PE cloth can be white or blue, it can be changed if broken. horse kick can't damage the cloth but if sharp point or edge maybemake the cloth broken.
PE cloth | 3494*1194*10mm |
Length*Height | 3-3.2m*2.2m |
PE cloth | 2194*1194*10mm |
Swing door | 1190mm*2030mm |
PE cloth of swing door | 1094*1184*10mm |
We house a large ranger of internal stables ranging from temporary stables right through to luxury sweeping stables complete with brass finials. Whatever your budget we have a design that will transform your yard.
* Our most stylish stable design with curved features.
* The main post finished with impressive finials or caps.
* Optional hinged(swing) or sliding doors.
* Q235 steel according to EN standard, stainless steel and aluminum is available.
* Powder coated or HDG in surface treatment (choices of colors).
* Optional hay/grain feeding bowl access door.
* Integrated panel comprising of recycled plastic, hardwoods or heavy duty bamboo.
* The main post finished with impressive finials or caps.
* Optional hinged(swing) or sliding doors.
* Q235 steel according to EN standard, stainless steel and aluminum is available.
* Powder coated or HDG in surface treatment (choices of colors).
* Optional hay/grain feeding bowl access door.
* Integrated panel comprising of recycled plastic, hardwoods or heavy duty bamboo.
Size | 3m, 3.6m, 4m |
Height | 1.8m, 2.2m, 2.4m |
Material | Q235 steel, 304SS |
Panel insert | Hardwood, Recycled PVC or WPC, heavy duty bamboo28/30/32mm |
Door style | Hinged/swing or sliding |
Surface | Hot dip galvanization, Powder costing or metal painting(color is selected). |
Usage | Private club, sports center. Events or fair show. |
Fix way | Temporary or Permanent, internal or outdoor |
Accessories | Swing bowl and water feeder optional |
Main post | 89,104,127mm optional |
Roof | Optional |
Connection | Bolt or Reeds plug |
Sliding door assembly instruction
1， top rail. the rail is connected by part 2 by nut.
2, rail hanger/holder. the holder will lock the rail tightly. one end is connected to the side pole top. second end is connected to left front top. the nut is welded and left in both place.
3, door slide automatic lock, the spring pole will slide into the lock hole and positioned. you just need take the pole out the hole by hand when you want to open the door.
4, slide door bottom positioner. which keep the door in straight line movement.
2, rail hanger/holder. the holder will lock the rail tightly. one end is connected to the side pole top. second end is connected to left front top. the nut is welded and left in both place.
3, door slide automatic lock, the spring pole will slide into the lock hole and positioned. you just need take the pole out the hole by hand when you want to open the door.
4, slide door bottom positioner. which keep the door in straight line movement.
- 5. top door stopper, which keep the door don't move out the rail. it's black rubber parts and keep quiet stop.
6, the hanger roller, made by nylon and be quiet moving. one end is sink into the rail and the other end connected to the hang door by nut.
Packing&Shipping
Size Information
Customized size is acceptable
Size | 3m, 3.6m, 4m |
Height | 1.8m, 2.2m, 2.4m |
Material | Q235 steel, 304SS |
Panel insert | Hardwood, Recycled PVC or WPC, heavy duty bamboo28/30/32mm |
Door style | Hinged/swing or sliding |
Related Products
Company Introduction
Our Services & Strength
we are one of top manufacturer for the equestrian products and horse stall,arena building and all equipment from arena leveler to horse walker.
Already exported to 30 countries in the world till now. We provide all products which you use in your horse yard,
jumps arena, show jumping and dressage. One-stop service. We supply free cost design for valuable client who can put their logo or special design for sponsor in the eventing.
jumps arena, show jumping and dressage. One-stop service. We supply free cost design for valuable client who can put their logo or special design for sponsor in the eventing.
One stop service from design, manufacture to shipping.
Close to Beilun port is only 30 mins to save cost for client.
FAQ
Q1: What‘s your strength comparing to other supplier?
Reeds mechanical is a professional factory who only focus on equestrian products and horse husbandry industrial.
We make everything by ourselves from arena ground surface, jumps to arena machine.
We are Longine master partner who provide full set equipments to China 3 Star FEI competition.
Q2: Why will we choose your company?
Price competitive, 30 mins to Beilun seaport, one stop service from design to production.
All our machine and equipment design is according to EU standard.
We have team in Denmark and Chile for design and sales. After sale service is guranteed by local service.
Q: Can we get a free sample?
Yes, you can if you can do collection express. it's only for small size product.
Q: Can you make a quick delivery?
Yes, for show jumps we have regular in stock. for traditional and portable stable, we have in stock.
for Arean surface footing and horse walker, arena leveller we can deliver within one week.
Q: What's brand you use for sell ?
Reeds睿姿@ and Arenaplus@ is our company trade mark.
Q: Can we use our own brand/logo for selling in our market?
Absolutly you can. Customized design and logo is highly welcomed.
Reeds mechanical is a professional factory who only focus on equestrian products and horse husbandry industrial.
We make everything by ourselves from arena ground surface, jumps to arena machine.
We are Longine master partner who provide full set equipments to China 3 Star FEI competition.
Q2: Why will we choose your company?
Price competitive, 30 mins to Beilun seaport, one stop service from design to production.
All our machine and equipment design is according to EU standard.
We have team in Denmark and Chile for design and sales. After sale service is guranteed by local service.
Q: Can we get a free sample?
Yes, you can if you can do collection express. it's only for small size product.
Q: Can you make a quick delivery?
Yes, for show jumps we have regular in stock. for traditional and portable stable, we have in stock.
for Arean surface footing and horse walker, arena leveller we can deliver within one week.
Q: What's brand you use for sell ?
Reeds睿姿@ and Arenaplus@ is our company trade mark.
Q: Can we use our own brand/logo for selling in our market?
Absolutly you can. Customized design and logo is highly welcomed.
