MUP-C758 завод 6pin мобильного телефона женский гнездо sim-карты Держатель Разъем для чтения

Описание и отзывы

Характеристики

MUP-C758 card connector



Technical characteristics



1.General characteristics

   Dimensions:17.10L*16.80W*3.70H mm

   Weight:0.45g

   Contact principle:Friction technology

   Operating position:shaft up/down/horizontal

   Mounting system:SMT(post optional)

   Durability:1500 cycles min



2.Mechanical characteristics

   Insulation material:Thermoplastic



3.Electrical characteristics

   Number of contacts(optional:6pins

   Contact resistance:50MΩ typical,1000 MΩ max

   Insulation resistance:>1000 MΩ/500V DC



4.Solderability

   Wave:not applicable

   Vaporphase:215^oC,30sec Max

   IR reflow:230^oC,15sec Max

   Manual soldering:not applicable



5.Environmental characteristics

  Operating temperature:-25^oC≈ +70^oC

  Operating humidity:10%≈+95%RH

  temperature:-40^oC≈+85^oC

  Storage humidity:10%≈+95%RH

  Thermal shock: -40^oC+85^oC,5cycles

  Damp Heat:40^oC,90%RH,10days

  Salt-mist:35^oC,5%Nacl,24H





Company Information





Brief  Introduction



MOQ	♦ 3000pcs
Price Term	♦ FOB Shenzhen
Payment Terms	♦ T/T, Paypal
Delivery	♦ UPS, DHL, FEDEX,TNT ♦ Select the most economic and efficient way. ♦ Sent the tracking number to u after delivery.
Samples	♦ Free samples will be sent on request. ♦ The samples lead time is within 3-5 days after u confirmed.
Packing	♦ Inside: reel packing   ♦ Outside: carton













































Applications





They can be used to operate all types of computers,  POS, ATM, DVD, TV, electronic meters, water meters, gas meter, set top box, balance reader, mouses, mobile phones, cameras, VCRs, stereo and car radio equipments, PDAs and home applications,medical equipment etc.





Delivery











 Prompt Delivery & Lowest shipping cost : We can get low discount from DHL, Fedex, UPS, TNT, EMS, etc.





Certificate



passed the ROHS & ISO9001
