850nm 42mil ИК светодиодный чип SMD 3838 EMC 70 градусов диод поверхностного монтажа
- Категории: Светодиод высокой мощности >>>
- Поставщик: Shenzhen,Oceanstar,Electronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product properties:
Package size:3.8*3.8MM
Wavelength:850/940nm
Radiant Intensity Ie:130-160mw/sr
Radiant Flux:700mw
VF:1.4-2.1v
View Angle:50°/70°/90°
IF:700/1000mA
Product characteristics:
1.Adopt the latest Quad infrared chip
2. Low power consumption, high light output efficiency, long life, low thermal resistance, in line with the Rosh standard
3. EMC bracket, good heat dissipation performance
Product details:
Model | Wavelength | Package size | Luminous angle | Working current | VF | IE mw/sr | PO |
JNJ-3838JI0113B90/42MIL | 850 | 3.8*3.8 | 90 degree | 1000MA | 1.4-2.1V | 310-340 | 690 |
JNJ-3838JI0113B90/35MIL | 850 | 3.8*3.8 | 90 degree | 1000MA | 1.4-2.1V | 220-260 | 600 |
JNJ-3838JI0111B90/28mil | 850 | 3.8*3.8 | 90 degree | 700MA | 1.4-2.1V | 180-220 | 420 |
JNJ-3838JV0113B90/42mil | 940 | 3.8*3.8 | 90 degree | 1000MA | 1.4-2.1V | 285-315 | 670 |
JNJ-3838JI0113B70/42MIL | 850 | 3.8*3.8 | 70 degree | 1000MA | 1.4-2.1V | 490-530 | 620 |
JNJ-3838JI0113B50/42MIL | 850 | 3.8*3.8 | 50 degree | 1000MA | 1.4-2.1V | 490-530 | 620 |
JNJ-3838JI0113B30/42MIL | 850 | 3.8*3.8 | 30 degree | 1000MA | 1.4-2.1V | 340-410 | 680 |
