Item | Function | Description |
Hardware Function | CPU | AK3760C |
Fingerprint scanner | Optical fingerprint head(DEG931 20pin) | |
ID card | supported | |
Display | 2.4”,2.8” TFT LCD(same as M61) | |
Keyboard | 16 Physical keys | |
Communication method | Cable Network,WIFI | |
USB HOST | supported | |
Clock RTC | supported | |
Voice output | supported | |
Access control function | Professional access control ( Open door relay, ring bell relay, door magnetic switch, open door button, anti-demolition button, Wiegand input and output) | |
Clear administrator key | supported | |
Backup battery interface | supported | |
Operating voltage | DC 9V~12V | |
Working temperature | -10℃~ +60℃ | |
Working humidity(RH) | 20% ~ 80% | |
Software Function | Log capacity | 3000(16M Flash) |
Attendance Log capacity/Mgt. Log capacity | 100000/3000 | |
Identify mode | Face, Fingerprint, card, password and combinations | |
Language |
| |
Fingerprint Algorithm | Algorithm version | Green Finger V3.0 |
FAR/ FRR | 0.00001/ 0.1(%) | |
Matching speed | ≥1 time/s (when 3000 Fingerprints logged) | |
Contrast angle | 360 degree free rotation | |
Intelligent update function | supported | |
Fingerprint recognition mode | 1:1, 1:N |
1. Transportation and handling
1).DHL, FedEx, TNT, ups usually take 3-5 days, depending on the country.
2).Speed post is slow; It usually takes more than eight days, and mail is much slower in Hong Kong
3).We are not responsible for any accidents, delays or other issues which fall under the responsibility of shipping services.
4).Please make sure that you pass through the customs without difficulty.
5).To ensure that you receive your order duty free when you import it, we would like to declare it as a gift or as a free sample of lower value.
2. Return
1).If the product is defective; please inform us within 7 days after delivery.
2).All items must be returned as is in order to qualify for a refund or replacement.
3).Items returned 10 days after delivery can only be repaired. The buyer is responsible for all shipping costs incurred
4).All products have been tested before delivery and are in good condition. If the products are damaged during transportation, it is not our responsibility.
3. The feedback
If you leave good or best feedback, we will be grateful and if you have any questions or suggestions, we will try our best to solve any problems. Please do not leave any negative feedback before contacting us.
