Шэньчжэнь индивидуальные печатные платы производитель
- Категории: Пассивные компоненты >>>
- Поставщик: Shenzhen,POE,Precision,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Details
Capability
Layer | 1-28 | ||||
Copper Thickness | 0.5-6oz | ||||
Material | FR4, HI-TG, FR06, Argon, Nalco, Isola ... | ||||
Solder Mask | Green, Yellow, Red, Blue, Black, White .... | ||||
Finished Surface | Conventional Hasl, Lead Free Hasl, Immersion gold/Tin/Silver, Hrad gold, OSP... | ||||
Silkscreen Color | White, Black ... | ||||
Minimun line width/gap | 3.5/4 mi l( laser drill ) | ||||
Minimum Hole Size | 0.15mm ( mechanical drill )/4 mil ( laser drill ) | ||||
Minimum Annlar Ring | 4mil | ||||
Max Copper Thickness | 6oz | ||||
Min Solder Mask Bridge | 0.08mm | ||||
Plugging Vias Capability | 0.2-0.8mm | ||||
Lead Time
Layer | Prototype | Mass Production ( above 30㎡ ) | ||||
Quick Turn | Usual TIme | |||||
2 | 24 hours | 3-4 days | 8-10 days | 8-10 days | ||
4 | 48 hours | 5-6 days | 12-14 days | 12-14 days | ||
6 | 72 hours | 6-8 days | 14-16 days | 14-16 days | ||
8 | 72 hours | 8-10 days | 16-18 days | 16-18 days | ||
... | ... | ... | ... | ... | ||
Company Profile
POE Precision Electronics CO.,Ltd
POE is an OEM manufacturer that focus on PCB&PCBA manufacturing over 23 years. We have capability to manufacture PCB ranging from basic single sided boards up to 28 layers, and provide one-stop turkey services, programming, function testing and housing. We established in 1996 and always provide high quality, technically advanced products within the customer's timescales so that we can provide the best electronic services for you. This commitment, combined with the wealth of experience and expertise we have built up over the years, means we can offer a total solution to our customers PCB requirements - from front end engineering through to in time deliveries.
FAQ
Q1. What is needed for PCB and PCBA quotation?
PCB : Quantity, Gerber file and technic requirements ( material, surface finish treatment, copper thickness, borad thickness..)
PCBA : PCB information, Bom list. ( Testing documents...)
Q2. What file formats do you accept for PCB&PCBA production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
Bom: Excel ( PDF, Word, TXT)
Q3. Are my files safe?
Your files ase held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.
Q4. MOQ?
There is no MOQ in POE. We are able to handle Small as well as large volume production with flexibility.
Q5. Shipping cost?
The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost
Contact us
