LESINTOR точный контроль температуры для выдувной машины Водяной охладитель горячая распродажа промышленный обработки

LESINTOR точный контроль температуры для выдувной машины Водяной охладитель горячая распродажа промышленный обработки

Цена:798,00 $ - 1 088,00 $*

Стоимость в USD (на сегодня):Узнать

Количество:

Water Cooled Chiller
Parameter/Model			03WC	05WC	06WC	08WC	10WC	20WC	25WC	30WC
Cooling Capacity	KW/hr	9.59	15.91	19.18	24.85	31.83	67.14	81.53	99.19
Cooling Capacity		Kcal	8251	13690	16503	21370	27370	57748	70120	85303
Temperature Range			5℃-room temperature(Below 0℃ Could be Customized)
Voltage			3N-380V 50HZ
Power	KW	2.575	4.50	5.25	6.75	9.00	17.20	20.95	26.00
Control Method			Capillary Tube								Expansion Valve
Compressor	Type	Hermetic Scroll Type or Piston
		Quanlity	1					2						3
		Power(KW)	2.20	3.75	4.50	6.00	7.50	15.00	18.75	22.00
		Refrigerant	R22
Condenser	Form	Straight Pipe Type
Evaporator	Water Volume(M3/H)	1.65	2.75	3.30	4.27	5.47	11.55	14.03	17.06
		Water Capacity(M3)	0.05	0.06	0.06	0.15	0.15	0.30	0.38	0.38
		Water Tank Capacity(L)	45	50	60	140	145	245	270	300
		Import and Export Caliber	DN25								DN50	DN65	DN65
Pump	Power(KW)	0.37	0.37	0.37	0.75	0.75	4.0.	4.0	4.0
		Water Discharge(L/MIN)	90	90	90	170	170	800	800	800
		Water-lift(M)	18	18	18	14	14	21	24	24
Dimension	L(MM)	870	870	870	1300	1300	1750	1750	1800
		W(MM)	550	550	550	680	680	760	760	800
		H(MM)	900	900	900	1300	1300	1500	1500	1500

Air Cooled Chiller
Parameter/Model			01AC	02AC	03AC	05AC	08AC	20AC	25AC	30AC
Cooling Capacity	KW/hr	2.94	5.67	8.39	13.95	21.80	59.08	71.72	87.20
Cooling Capacity		Kcal	2528	4872	7216	11990	18747	50805	61683	74992
Temperature Range			5℃-room temperature(Below 0℃ Could be Customized)
Voltage			1N-220V 50HZ			3N-380V 50HZ
Power	KW	1.27	2.02	2.85	4.86	7.65	18.80	22.75	28.50
Control Method			Capillary Tube Type								Expansion Valve
Compressor	Type	Hermetic Scroll Type or Piston
		Quanlity	1	1	1	1	2	2	2	3
		Power(KW)	0.75	1.50	2.20	3.75	6.00	15.00	18.75	22.00
		Refrigerant	R22
Fan	Air Volume	1000	2000	3000	5000	8000	20000	25000	30000
		Size(MM)	350	350	350	400	450	500	500	550
		Quanlity	1	1	2	2	2	4	4	4
		Power	0.14	0.14	0.17*2	0.23*2	0.43*2	0.55*4	0.55*4	0.55*4
Condenser	Form	Efficient Brass Sets Coorrugated Aluminum Fin
Evaporator	Water Volume(M3/H)	0.51	0.97	1.44	2.40	3.75	10.16	12.34	15.20
		Water Capacity(M3)	0.028	0.040	0.050	0.065	0.130	0.280	0.320	0.320
		Water Tank Capacity(L)	30	45	45	65	140	245	270	300
		Inport and Export Caliber	DN20	DN25	DN25	DN25	DN40	DN50	DN65	DN65
Pump	Water Discharge(L/MIN)	90	90	90	90	170	800	800	800
		Water-lift(M)	18	18	18	18	14	21	24	24
		Power(KW)	0.37	0.37	0.37	0.37	0.75	4.0	4.0	4.0
Dimension	L(MM)	436	750	1040	1300	1500	2000	2000	2400
		W(MM)	337	520	570	650	700	1100	1100	950
		H(MM)	753	800	1000	1100	1250	1780	1780	1780
