Factory direct sale Stake Semi Trailer with cheap price
Related Products
Click the product image below to view more products
Vehicle parameters
Weight
7000KGS
Payload
60000KGS
Overall Length
13000mm
Overall Width
2480mm
Chassis
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345; welded by automatic Submerged-Arc processes; Top Flange 14mm, width 140mm; Middle Flange 6mm, height 500mm; Bottom Flange 16mm,width 140mm
Axle
2/3 /4 axles
Brand name: BPW, L1 or FUWA
Suspension
Mechanical suspension or air suspension
Spring
Leaf spring or air bag
King Pin
JOST brand 2” Bolt-in King Pin
Landing Gear
JOST brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim
8.5-20 ,9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim
Twist Lock
12 no. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container
Tyre
11.00R20 , 12.00R20, 11R22.5,12R22.5,315/80R22.5
Spare Tyre
One set of spare tire including a carrier
Braking System
WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks
Painting
Complete Chassis sand blasting to clean rust; 1 coat of anticorrosive prime, 2 coats of final paint
Accessories
One standard tool box
Company Information
Workshop
Our factory with more than 20 years' experience. Being famous in domestic and foreign countries, we concentrate on trailer and truck's research and development. Our aim is to provide high quality and low price products for the customer. Experienced and technological team customize the best productions for customers. For any reliability& safety and economic related questions, we all have mature solutions at any time.
Certification
Henan Lishixin Logistics Equipment Co., Ltd is located in Zhengzhou FTA, Henan Province, China, with a registered capital of 3, 500, 000USD. Lishixin is specialized in the R & D, mass production and sales of kinds of the 20FT, 30FT,40FT ISO Storage Tank Containers and Storage Tanks as well as other special logistic Transportation equipments.Based on rich transportation advantages and resource of Central China, Lishixin is committed to supply high quality and cost-effective transportation equipment for clients all over the world.
FAQ&Purchasing Guide
Q:How is your warranty?
A:We prefer buyout service,but don't worry, we provide technical support and parts purchase channels throughout.If you need service, it’s all right, but the price may increase.
Q:What kind of Payment can you accept?
A:T / T and L/C is all right to us.
Q:How long will it takes to ship?
A:Around 15-25 working days.
Q:What is your MOQ?
A:1 Unit.
Q: How about the Color , Specific configuration things?
A:It's up to you , most of them are optional and can be changed by your needs.
1. You want to install tons/cbm? 2. It's used to transport ? 3. You need units?
4. Special requirements .
If you can provide those information, we will be able to make a quotation for you as soon as possible.
