Introduction Of Good Quality Plastering Width 80cm New Type Automatic Wall Plaster Machine Made In China

Wall Plastering Machine is also known as: Wall finishing machine. It is a machine specially designed for wall plastering. A hoist with a vertical gantry and a counter scraper frame is mounted on the upper surface of the chassis, and a hopper above the chassis and connected to the chassis is installed inside the two columns of the scraper frame. The hopper can be slidably attached to the two columns by the hoisting machine. One side of the gantry is provided with a discharge opening on the upper façade of the hopper, and a squeegee is mounted on the lower part of the discharge opening; in the hopper, along the width direction thereof Supported by a dial roller, the motor is connected to the dial by a speed reducer, and the other end of the hopper is provided with a feed port.zmwm06

Parameter Of Good Quality Plastering Width 80cm New Type Automatic Wall Plaster Machine Made In China

Model	ZB800-2A	ZB800-4A	ZB800-5A	ZB800-6A
Plastering Height	0-3.6 meters	30cm-3.6 meters	30cm-3.6 meters	0-3.6 meters
Plastering Thickness	2-30mm	2-30mm	2-30mm	2-30mm
Plastering Width	80cm	80cm	80cm	100cm
Capacity	500-700m2/8hours	500-700m2/8hours	500-700m2/8hours	500-700m2/8hours
Dimensions	1350*800*500mm	800*650*480mm	720*830*680mm	720*1000*680mm
Voltage/frequency	According to your demands	According to your demands	According to your demands	According to your demands
Weight	180KG	120KG	110KG	140KG
Surface	Smooth	Smooth	Smooth	Smooth
Vibrator	2 vibrators	2 vibrators	2 vibrators	3 vibrators
Juncture device	Yes	Yes	Yes	Yes
Smoothing knife	Yes	Yes	Yes	Yes
storage capacity	90-100KG	50-60KG	50-60KG	50-60KG
		ZB800-4A	ZB800-5A	ZB800-6A



Photos Of Good Quality Plastering Width 80cm New Type Automatic Wall Plaster Machine Made In China
