Контроллер кондиционера CAN bus панель контроля температуры

Power supply

DC24V(DC20±1V-32±1V)

Power consumption

4.5W

Current

Max.200mA

Dimensions

168X66X54mm

Input

1) Interior temp. sensor(25°C,Rb=5K,B=3274)
2) Left/right evaporator sensor (25°C,Rb=5K,B=3274)
3) Left/right condenser sensor (25°C,Rb=5K,B=3274)
4) Left compressor pressure switch
5) Right compressor pressure switch
6) Backlight power
7) ACC power(battery)
8)Voltage detecting signal

Output

1)excitation output (max 0.3A)
2) Evaporator fan high (max 0.3A)
3) Evaporator fan medium (max 0.3A)
4) Evaporator fan low (max 0.3A)
5) Fresh air on (max 0.3A)
6) Left/right four-way valve (Max. 0.3A)
7) Left/right compressor clutch (Max.0.3A)
8) Transducer on (Max.0.3A)
9)Transducer H (Max. 0.3A)
10)Transducer L (Max. 0.3A)
11)Left/right condenser output (Max 0.3A)

Display

LED (red)

Ambient temperature

-30°C—80°C 5%-95%RH Non-condensing

Storage temperature

-10°C—70°C 5%-95%RH Non-condensing

Display precision

Set temp for dual digit display, accuracy 1°C; Interior temp dual digit display. accuracy1°C

Humidity test standard

Temp. control based on the temp. of return air inlet. In cooling mode, defrost on at –3°C, defrost off at 4°C. In heating mode,
defrost on at –3°C, defrost off at 10°C.

Connector

M4257-2*9 M4257-2*7

Faceplate level

IP43

EMC level

EN50081&EN50082-2

Security level

Applied to EN61010-II, Pollution degree: II

Weight

260g
