Однополюсный клавишный переключатель ANHEDA однополюсный реактивный и лодочный Электрический с двойной защелкой


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики


Product Description

ANHEDA single-pole rocker switch single pole rocket swtich&boat double latch illuminator electric






Switch electrical lifetime above 10,000 cycles

Product details


Rating 6A/250V AC, 10A/125V AC
Rated Load 2/8A 250V AC
Contact Resistance ≤50M
Dielectric Intensity ≥1500V AC/min
Withstand Voltage 1500V AC/min
Temperature -25~85°C
Insulation Resistance ≥100M
Life ≥10,000 cycles
Function ON-OFF/ON-ON/ON-OFF-ON
Product Keywords single-pole rocker switch



Features:


Features

Easy installation by simply drilling a 3/4" hole. Key hole slot to prevent turning.

Handles up to 6 Amps

Advantage

1) We have CE,RoHS,CQC for rocker switch.

2) Switch electrical lifetime above 10,000 cycles.

3) R & D team for Automation, mould & new product.

4) Automation systems.

5) Mould developing systerms.

6) New item developing according to your samples or drawings.





Quality assurance:


IQC, IPQC, PQC, OQC. Inspect for supplied material, production process and final product, including withstand voltage, insulating resistance, conductor, dimension, external appearance, etc. All elated raw materials are inspected as Rohs requires.






single-pole rocker switch


Product Specifications
Specification of Rocker Switch
Rating16A/250V AC, 20A/125V AC
Rated Load2/8A 250V AC
Contact Resistance≤50MΩ
Dielectric Intensity≥1500V AC/min
Withstand Voltage1500V AC/min
Temperature-25~85°C
Insulation Resistance≥100MΩ
Life≥10,000 cycles
Pins4/6
FunctionON-OFF/ON-ON/ON-OFF-ON
Illumniated220V Neon Lamp
APPROVALS
CECQCRohs



Detailed Images

single-pole rocker switch
Material DetailsPartMaterial
Base PlasticNylon
Button PlasticPA66/ PC
Terminal Brass(tin plated)
ContactCompound silver/ Copper
SpringTungsten steel
Waterproof CapPVC ( If you required)
MountSnap in

Application:

Small household products, communication equipment, energy generator, electric tools, table lamp, electric motor, electric motor car, electric toy, UPS, medical facilities, socket, etc

single-pole rocker switch

Terminal Type
A4.8*0.8single-pole rocker switchG6.3*0.8single-pole rocker switchM2.5*0.5single-pole rocker switch
B4.8*0.8H6*0.8N5.6*0.5
C3*0.8I3.8*0.8P2.8*0.5
DPCJ2.7*0.5
EPCK6.3*0.8
F6.3*0.8L



Hot Selling Products

single-pole rocker switch

Company Information

\tsingle-pole rocker switch

Yueqing Anhe Electronics Co.,Ltd.


Established in 2003, we are engaged in producing 12 categories and about 2,000 models of rocker switches,push button switches, toggle switches, micro switches, key switches,tact switches,slide switches and etc. Most of our products have passed safety certifications as CE, CQC. And lots of our products are made with RoHS compliant materials.




\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t

single-pole rocker switchsingle-pole rocker switch


\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
Our Advantages

\t

\t

\t

PRICE


\t

As a manufacture, all of our switch parts are made by our own factory. So the price is competitive.


\t

\t

\t

ADVANTAGES


\t

\t

\t

SERVICE


\t

24 hours on-line professional engineer and business reception will feel free to serve you.


\t


\t

\t

OEM & ODM


\t

Various operating force,height and colour for one switch for your choice.


\t

\t

\t

QUALITY


\t

We have our own testing lab in factory, so quality can be guaranteed.


\t

\t

\t

DELIVERY


\t

Spare production line and on-line stocks inquiry are the most powerful assurance for customers' needs.


\t

\t


\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
Packaging & Shipping

\t

single-pole rocker switch




 Shipping


INTERNATIONAL AIR MAIL


 Payment


 Fast Delivery


Different amount of time will be required for different


\t\t\t\t\t
\t\t\t\t
\t\t\t\t\t
\t\t\t\t
FAQ

\t single-pole rocker switch
\t

\t \t

\t \t \t

\t \t \t \t

1.When can we get the reply?


\t \t \t \t

Any inquiries will be replied within 24 hours.
Our sales team will try our best to support you.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

2.What about minimum order quantity?


\t \t \t \t

Generally our MOQ for rocker switches is 10000pcs, and for mirco switches is 50000pcs.
Also you can place a Trial orders at first without limit for MOQ.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

3.Can customize,modify and develop products according to the design drawing?


\t \t \t \t

Yes,we provide OEM service and can customize products according to the drawing.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

4.How will you control product quality?


\t \t \t \t

We strictly control every detail of production, and every product is inspected by our QC team before delivery. Moreover,our production is abided by CQC,CE and RoHs.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

5.What about delivery time?


\t \t \t \t

Samples, We will send to you within 3 days after payment received. Production for big quantity needs 7 to 15 days. And it also depends on product and quantity.
If you want to know the exact time. Email us the quantity, we will check the delivery time for you.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

6.What about terms of payment?


\t \t \t \t

Payment terms: T/T, west Union and L/C etc


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

7.How do I know that you have sent the products out?


\t \t \t \t

Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times.


\t \t \t

\t

\t

\t \t \t

\t \t \t \t

8.How you will send the goods to us?


\t \t \t \t

We will send the goods to you by sea, by air or by express like DHL, UPS, TNT, FEDEX,CHINA POST.
