specification:
Function | 1. Car charger: Dual USB output 5V-2.1A |
2: GPS tracker: Realtime GPS/AGPS/LBS/Wifi Positioning, Geo Fence Alarm Reminder, historical track | |
CPU | 2503D,Assisted Chip: 3333 + 5931 |
ROM | 32MB |
RFPA | 6625E |
Size | 75*43*26mm |
Working Temperature | -20℃ - +70℃ |
Network | GSM850/900/1800/1900MHz, working with GPRS 12 |
GSM Antenna | PIFA Antenna |
SIM slot | Support NANO sim card |
TF Slot | Support TF card up to 32GB |
GPS Antenna | 15X15 High performance ceramic antenna |
GPS Positioning Accuracy | Within 10Metres |
GPS Motion Accuracy | 0.1metre/second |
GPS Positioning Time | Cold Boot-38s(Open field), Warm Boot2s(Open field),The specific time is affected by the environment |
WIFI Positioning Accuracy | Within 50Metres |
GSM Positioning Accuracy | 50-200Metres (Depending on the network) |
Battery | Plug and play, powered by car charger socket, automatically power on/off when your car engine start/stop |
Charging port | Car charger socket |
MIC | Built-in High-Definition Silicon microphone |
Horn | 0916 AAC |
Sensor | Build-in 3D G-sensor |
Attention:
1: This model can only work with 2G GSM network(GSM 850/900/1800/1900,support Nano sim card), make sure the GPRS network is available,please confirm your network with your local telecom operators.
2: Before your large scale quantity orders, we kindly suggest testing our samples in advance.
3: We offer free apps for our users for all our GPS tracker products.
4: For your own server, we are able to help you to transfer the communication protocol.
5: We are able to offer any necessary firmware & software technical assistance
Standard export carton packing.
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
