Стальной медный алюминиевый гравировальный и сверлильный ЧПУ-роутер 4040 для


Поделиться:

Цена:3 000,00 $ - 3 300,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Machine Images


Steel, copper,aluminum engraving and drilling cnc router 4040 for sale





Feature of cnc metal router AK4040:
1.The machine body structure adopt cast iron, the rigidity is good, not easy to be deformed, to make sure the machine’s stability.
2.Well compatibility: compatible for software CAD/CAM, such as type3/artcam/JDPaint/proe/ug.rtc
3.Heavy loading, non-deformation, adopting imported double nut screw to ensure the engraving speed. Adopting Taiwan’s high-precision square linear guide, effectively imported the precision of carving.
4.Adopt high-speed water cooling motor with invariably power, big torque,strong cutting, high-frequency and long-life.
5.Available for continuous work for a long time.



Machine parameter


Model
AK4040
XYZ working area
400*400*150mm
Table size
400*400mm
Traveling Positioning Accuracy
±0.03mm
Repositioning Accuracy
±0.03mm
Table surface
T slot Table
Table frame
Whole cast steel
Transmission
TBI Ball screw from Taiwan
Guide rails
HIWIN Linear guide rail
Max power consumption
(without spindle)
6000mm/min
Max rapid travel rate
4000mm/min
Spinle power motor
2.2kw water cooling spindle
Spindle speed
0-24000RPM
Drive motor
Stepper motor
Working voltage
AC20V/380V 50/60Hz
Command code
G code
Opreating system
Mach 3 controller
Inverter
Fuling Inverter
Bearing holders
Original from Taiwan
XY resolution
<0.01mm
Software
Type3 /Artcam
Running environment
Temperature:0-45 °C
Humidity: 30%-75%
Package size
1120*1070*1720mm
Net/Gross weight
180/240kg


Product Detail


Water cooling spindle
TBI Ball Screw


Cast Iron sturcture
Cast Iron table


Mach 3 Controller
Water cooling spindle


Options:


Rotary Axis
Realize local rotary machining, reduce finishing allowance and complete tool path calculation at one time
Leadshine servo motor

Fast speed, more convenient, save processing time, high control accuracy
DSP controller

featuring delicate appearance,powerful functionality and flexible operation.


Application and Working Samples


Applications :

1.It is suitable for engraving,milling and drilling compactly all sorts of materials such as steel,copper,aluminum and plastics.
2. It can widely apply to automotive,injection mould,ironware mould and engrave mould industries.
3. Especially designed for engraving and milling molds,eyeglasses, watch,panel,badge,brand, graphics and words of three-dimensional and outside surface's sleeking of large size.






Our Services


1)1years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2)Lifetime maintenance free of charge.
3)Free training course at our plant.
4)We will provide the consumable parts at an agency price when you need replacement.
5)24 hours on line service each day, free technical support.
6)Machine has been adjusted before delivery.
7)Our staff can be sent to your company to install or adjust if necessary.
