Грузовик для сбора мусора с задней загрузкой

[Technical parameters of the whole vehicle]

product trademark

Cheng Liwei brand

Bulletto

314

product name

Factory price side loading garbage collector

Total mass (kg)

8280

Tank volume (m3)

Rated mass (kg)

1655

Shape dimension (mm)

7400,

7200X2250X2750

Preparation quality (kg)

6430

Box size (mm)

XX

Rated passenger (person)

Total mass of the quasi-trailer (kg)

Number of passengers in the cab (person)

3

Saddle maximum load mass (kg)

Approaching angle/ angle of departure (°)

24/13

Front suspension/ rear overhang (mm)

1085/790,1110/790

Axle load (kg)

3000/5280

Maximum speed (km/h)

100

Note:

Note: 1, the car only uses 3815mm wheelbase, the car has five optional flip styles, A: triangular bucket device, B: bucket device, C: swing arm device, D: large landing bucket device, E: no rear flip device. When ABCD is selected, the corresponding relationship of the total length (mm) / rear suspension (mm) is 7400 ≤ 2475, and when E is selected, the corresponding relationship of the total length (mm) / rear suspension (mm) is 7.2002275.2, protective material: Q235carbon steel, connection mode: the left and right side protection is welded to the auxiliary beam, and the rear protection is replaced by the special device. 3. The corresponding relationship between the selected engine model and the fuel consumption value (L/100km) is: WP3Q130E50/18.3.4, with the chassis optional cab. 5, special device: box body, mainly used for the collection and transfer of municipal sanitation domestic waste.

[Chassis technical parameters ]

Chassis model

HFC1081P91K1C5ZV

Name of chassis

truck chassis

brand name

Jianghuai brand

manufacturing enterprise

Anhui Jianghuai Automobile Group Co., Ltd.

number of axles

2

Number of tyres

6

Wheelbase (mm)

3815,3365,4150

tyre size

7.50-16LT 14PR,7.50R16LT 14PR,8.25R16LT 14PR

Number of leaf springs of steel plate

8/6+6,9/12+6,9/6+6,8/12+6

Front wheel distance (mm)

1685

fuel type

diesel oil

Rear wheel distance (mm)

1600

emission basis standard

GB17691-2005 State V,GB3847-2005

engine type

engine production enterprise

engine displacement

engine power

WP3Q130E50

D30TCIE1

Heilongjiang Diesel Power Yangzhou Diesel Engine Co., Ltd.

Kunming Yunnei Power Co., Ltd.

2970

2977

96

115
