Product name

6 ports Gigabit Intelligent Industrial PD POE Switch

Model

HR600-AXGR-411S

Connector Type

4*Gigabit POE ports+1*Gigabit Uplink Ethernet port(60W POE power)+1*Gigabit SFP port ;Port 1 supports BT 90W power supply

Network Protocols

IEEE802.3

IEEE802.3x

IEEE802.3u

IEEE802.3ab

IEEE802.3z

POE Parameters

POE Standard: IEEE802.3af /IEEE802.3at /IEEE802.3bt

Each port Max:15.4 W (IEEE 802.3af)

Each port Max:30 W (IEEE 802.3at)

BT port 1:90W (IEEE802.3bt)

POE port output: DC 48-55V

POE power supply core:1/2+ ; 3/6-(4/5+;7/8-)(1/2-;3/6+)

Network Media

10BASE-T: Cat5 UTP(≤250 m)

100BASE-TX: Cat5 or more UTP(≤100 m)

1000BASE-TX: Cat5 or more UTP(≤100 m)

Fiber Media

Multi-mode:850nm,1310nm   transmission distance:550m/2Km

Single-mode:1310nm,1550nm  transmission distance:20/40/60/80/100/120Km

Dial function

VLAN:1-4 ports are isolated from each other (left, lighting) .POE watch dog is on

Default:Normal mode (middle, off) POE watch dog is off

Extend: The port 4 is 10M  250m (right,flash)POE watch dog is on

LED indicator

PWR

(Power Indicator)

Lighting:Powered

Un-Light:No Power

Mode

(Dail Indicator)

Lighting:VLAN

Un-light:Default

Flash:Extend

Link

(port indicator)1-6

Lighting:Connecting
Flash:Data Transmit
Un-light:Disconnect

POE

(POE indicator)

1-4

Lighting:POE Powered
Un-light:No Power

PD

(Power receiving indicator)5

Lighting:Receiving power
Flash:power negotiation
Un-light:No Receiving power

Power Supply

Power input: DC 48~55V/uplink POE power

power supply wiring :4 PIN Industrial Phoenix Terminal (redundancy V1+V1-,V2+V2-)

Working Environment

Operating Temperature: -40~85℃

Storage Temperature: -40~85℃

Humidity: 5%~95 %( non-condensing)

Industry Standard

EN61000-4-2 (ESD) contact 8KV, air 15KV
IEN61000-4-5 (Surge)common mode 6KV, differential mode 2KV
EN61000-4-3 (RS)
EN61000-4-6 (CS)

EN61000-4-4 (EFT)

FCC Part 15/ CISPR32 /EN55032: CLASS A

IEC 60068-2-27 Shock test

IEC 60068-2-32 Free fall test

IEC 60068-2-6  Vibration test

Mechanical Structure

Shell protect grade: IP40

Installation: DIN rail

N.W:0.5KG  G.W: 0.7KG(without power supply)

Product Dimension (L×W×H): 145mm×108mm×40mm

Package Dimension (L×W×H): 240mm×207mm×55mm

Package Contents

1. Industrial Switch: 1 unit

2.User Guide:1unit

1.Certificate warranty card:1unit

Certification

CE,FCC,CCC,RoHS

MTBF

100,000 hours

Warranty

5 years

Hardware parameter

Bandwidth

12Gbps

Cache

1M

Package Forwarding Rate

8.928Mpps

MAC address

8K

Forwarding mode

Store-and-forward
