Пружинная Стопорная шайба Monel K500 из никелевого сплава

Пружинная Стопорная шайба Monel K500 из никелевого сплава

Категории: Washers >>>
Поставщик: Zhengzhou,Huitong,Pipeline,Equipment,Co.,Ltd.

Цена:5,00 $ - 7,00 $*

Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики

Monel K500 nickel alloy spring lock washer DIN127

Monel K500

Monel K500® is a nickel-copper alloy with the same corrosion resistance and characteristics as the Monel 400®. Due to added aluminum and titanium the nickel alloy Monel K-500® has a greater strength and hardness than the 400. In age-hardened condition, Monel K-500 also has greater tendency toward stress- corrosion cracking in some environments.

ASME SB165 Monel K500 Seamless Pipes Equivalent Standards

STANDARD	WERKSTOFF NR.	UNS
Monel K500	2.4375	N05500

Chemical Composition of Grade K500 Monel Pipes

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel K500	0.25 max	1.5 max	0.5 max	0.010 max	27.00 - 33.00	0.5 - 2	63.00 min

Mechanical Properties of ASTM B725 Alloy UNS N05500 Welded Pipes

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel K500	8.44 g/cm3	1350 °C (2460 °F)	Psi – 160000 , MPa – 1100	Psi – 115000 , MPa – 790	20 %

Fasteners
Type	Stud Bolt	Threaded Rod	Hex Socket Cap Screw
	Hex Nut	U-Bolt	Spring Washer
	Pain Washer	Hex Bolt (full thread, partial thread)
Size	Stud Bolt	DIN: M6~M100	ASME: 1/4"~5"
Size	Hex Bolt	DIN: M6~M64	ASME: 1/2"~2 1/2"
Finish	Cold galvanizing, Hot-dip Galvanizing, PTFE, Zinc Nickel, Black coating, Plain
Producing Standard	ASME	ASME B18.2.1	Hex Bolts
		ASME B18.2.2	Hex Nuts
		ASME B18.22.1	Plain Washers
	DIN	DIN931	Hex Bolt with partial thread
		DIN 933	Hex Bolt with full thread
		DIN 912	Hex Socket Cap Screw
		DIN 934	Hex Nut
		DIN 125	Plain Washer
		DIN127	Spring Washer
		DIN 975	Threaded Rods
		DIN 976	Stud Bolts
		DN 3570	U-Bolt
Material Grade	Stainless Steel	304/304L, 316/316L, 316Ti, 317/317L, 321, 347/347H, 310, 309, A453 660C,660D, S31254 /254SMO, 904L /1.4539 /N08904, N08367, N08926 / 1.4529
	Duplex Steel	2205 /S31803, S32750/2507, S32760
	Nickel Alloy Steel	UNS N02200/Ni 200, UNS N02201 /Ni201, UNS N04400/ Monel 400, UNS N05500/ Monel K500 , UNS N06600/ Inconel 600, UNS N06601/ Inconel 601, UNS N06625/ Inconel 625, UNS N08825/ Incoloy 825, UNS N08800 /Incoloy 800, UNS N08810 /Incoloy 800H , UNS N08811 /Incoloy 800HT, UNS N08020 /Alloy 20, UNS N06002 /Hastelloy X, UNS N06022/ Hastelloy C22, UNS N06200/C2000, UNS N10276/ Hastelloy C276, UNS N10665 /Hastelloy B2, UNS N10675/Hastelloy B3, UNS N08020/ Alloy 20, UNS N08031/ Alloy 31
	Carbon Steel	Grade 4.8, 5.8, 6.8, 8.8, 10.8, 12.9
	Alloy Steel	A193 B7, A194 2H, A320 L7, L7M
