60В 72В 2000 Вт бесщеточным двигателем постоянного тока мотор контроллер для электрического транспортного средства
- Категории: Motor Controller >>>
- Поставщик: Zhongshan,Yuanxi,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
| Product parameter | |
| Input voltage | DC 60V-72V |
| Weight | 1.1KG |
| Output Current | 60A |
| Power | 2000W |
| Size | 213*105*57MM |
| Function | Three speeds(High . Medium . Low ) |
| The meter shows | |
| Low brake | |
| High brake | |
| Anti-theft device | |
| Reversing | |
| Self-learning function | |
| Output protection | Temperature protection 95°C |
| OverCurrent Protection | |
| Short-Current Protection | |
| Overvolatage protection | |
| Waterproof | IP55 |
| Storage temperature | -40℃-60℃ |
| Working temperature | -25℃-55℃ |
| Output Power | Input Voltage | Input Voltage | Input Voltage | Ampere |
| 350W | 12V-24V | 24V-36V | 48V-36V | 17A |
| 500W | 36V-48V | 48V-60V | 60V-72V | 27A |
| 800W | 48V-60V | 60V-72V | 72V-96V | 32A |
| 1000W | 48V-60V | 60V-72V | 72V-96V | 40A |
| 1200W | 48V-60V | 60V-72V | 72V-96V | 50A |
| 1500W | 48V-60V | 60V-72V | 72V-96V | 55A |
| 2000W | 48V-60V | 60V-72V | 72V-96V | 60A |
| 3000W | 48V-60V | 60V-72V | 72V-96V | 70A |
| 4000W | 48V-60V | 60V-72V | 72V-96V | 80A |
| 6000W | 48V-72V | 72V-96V | 96V-120V | 100A |
| 9000W | 48V-72V | 72V-96V | 96V-120V | 150A |
