Battery Features
Exclusive Patented Design
LITHTECH wall-mounted battery adopts a unique sunken and sunken sheet metal structure, so that all input/output ports and communication ports will not be exposed, so as to avoid damage to the ports after transportation or installation. At the same time, the battery owner will be protected from direct contact with the battery current port, with higher safety. On the other hand, hiding the output and communication ports can prevent them from being directly exposed to the air, improve the waterproof and dust-proof capacity of the battery, and extend the service life of the battery.
Battery Pack Nominal Characteristics
The battery pack uses a total of 16 aluminum shell LFP / AGB cells
16 in series and 1 in parallel to form 51.2V /100Ah,with a control system and connectors.
Protection Grade IP67
The basic parameters are as follows
Model No | TW | TW4000 | TW4000 PRO | TW6000 | |||
Voltage | 51.2V | 51.2V | 51.2V | 51.2V | |||
Capacity | 50Ah | 100Ah | 150Ah | 200Ah | |||
Operation voltage | 44-58.4Vdc | 44-58.4Vdc | 44-58.4Vdc | 44-58.4Vdc | |||
Max.charging voltage | 58.4Vdc | 58.4Vdc | 58.4Vdc | 58.4Vdc | |||
Max.charging and discharging current | 50A | 100A | 100A | 100A | |||
Max Power | 2560W | 5120W | 7680W | 10240W | |||
Life time(25°C) | 20 Years | ||||||
Life cycles(80% DOD, 25°C) | 8000 Cycles | ||||||
Storage time / temperature | 5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C | ||||||
Operation temperature | -20°C to 60°C @60+/-25% Relative Humidity | ||||||
Storage temperature | 0°C to 45°C @60+/-25% Relative Humidity | ||||||
Lithium Battery Standard | UL1642, IEC62619, UN38.3, MSDS,ROHS,CE-EMC | ||||||
Enclosure protection rating | IP21 | ||||||
Dimensions(L×W×H) | 600X400X160mm | 840X520X160mm | |||||
Weight | 29.5Kg | 51Kg | 81Kg | 93Kg | |||
Cell Specifcation
Model | LFP/AGB-100Ah |
Hull | AL |
Nominal Capacity (0.5C) | 100Ah |
Rate Voltage | 3.20V |
Charge Cut-off Voltage | 3.65V |
Discharge Cut-off Voltage | 2.50V |
Standard C/Discharge Current | 50A (0.5C) |
Max.Discharge Current | 200A(2.0C),continue 3min. |
Weight | ≈2.18kg |
Battery Impedance(AC 1kHz) | ≤1.0mΩ |
Standard Charger Way | After 0.5C constant current is charged to 4.2V, constan voltage 4.20V is charged until the current |
Operating Temperature | Charger 0℃-45℃ |
Discharger -20℃-60℃ | |
Storage -20℃-45℃ |
Products Description
MDSD；UN38.8；CE and Other Certificates
Lithtech energy storage batteries are compatible all off-grid/hybrid inverters.
If you want to get a whole solar energy storage system solution, please contact the customer manager of Lithtech, or directly click the picture above to transfer to the sales page of the solar energy system.
Large Project Display
USA EU CAN Warehouse
Factory Show
Our Exhibition&Customer
Package and Shipping
