Новый промышленный мини-коммутатор с 4 портами POE 100 м 1 волоконным портом

Specifications

I/O Interface

Power

DC  12~57V

Ethernet

4-Port  10/100M  RJ45

1-Port  100M Uplink fiber port (SC or LC port for optional)

Performance

Bandwidth

1Gbps

Package forwarding rate

0.744Mpps

Package Cache

512K

MAC

2K

Jumbo Frame

2Kbytes

Transfer

Store and forward

MTBF

100000  hour

Standard

Network protocol

IEEE802.3 (10Base-T)

IEEE802.3u (100Base-TX/FX)

IEEE802.3x (Flow control)

PoE Protocol

IEEE802.3af (15.4W)

IEEE802.3at (30W)

Industry Standard

EMI: FCC Part 15 CISPR (EN55032) class A

EMS: EN61000-4-2 (ESD),EN61000-4-4 (EFT),IEN61000-4-5 (Surge)

Shock: IEC 60068-2-27

Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

Network

10Base-T: Cat3, 4, 5 or above UTP(≤100m)

10Base-T: Cat5e or above UTP(≤250m)

100Base-TX: Cat5 or above UTP(≤100m)

 Media

Multimode fiber : 50/125, 62.5/125, 100/140μm

Single mode fiber: 8/125, 8.7/125, 9/125, 10/125μm

Certification

Security Certificate

CE,FCC,RoHS
