Электрод с платиновой
- Категории: >>>
- Поставщик: Tianjin,Aida,Hengsheng,Technology,Development,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Name: | Platinum plate electrode |
Product Number: | Pt213~Pt262 |
Product Type: | Platinum electrode |
Product Features: | The details of product size was listed as followed in parameter descriptions, which could be designed according to the customer requirements. |
Product Parameters | ||
Parameter descriptions | ||
Inner core material: | Platinum | |
Sheath material: | Glass, polytetrafluoroethylene | |
Purity of platinum: | Over 99.99% | |
Terminal length: | 20 mm | |
Sheath material length: | polyethylene: 80 mm; Glass: 100 mm | |
Electrode length: | Glass: 120 mm | |
Polytetrafluoroethylene: | 100 mm (The platinum plate is not included) | |
Product Number | Specification of Platinum sheet | Product Number | Specification of Platinum sheet | Product Number | Specification of Platinum sheet |
Pt213 | 2.5*4*0.1 2*5*0.1 | Pt216 | 10*15*0.1 | Pt242 | 15*15*0.3 |
Pt251 | 5*5*0.1 | Pt217 | 10*15*0.2 | Pt243 | 15*15*0.5 |
Pt252 | 5*5*0.2 | Pt218 | 10*15*0.3 | Pt224 | 20*20*0.1 |
Pt253 | 5*10*0.1 | Pt219 | 10*15*0.5 | Pt226 | 20*20*0.2 |
Pt254 | 5*10*0.2 | Pt212 | 10*20*0.1 | Pt228 | 20*20*0.3 |
Pt255 | 5*10*0.3 | Pt220 | 10*20*0.2 | Pt229 | 20*20*0.5 |
Pt210 | 10*10*0.1 | Pt221 | 10*20*0.3 | Pt230 | 10*30*0.1 |
Pt211 | 10*10*0.2 | Pt222 | 10*20*0.5 | Pt231 | 10*30*0.2 |
Pt214 | 10*10*0.3 | Pt240 | 15*15*0.1 | Pt261 | 30*30*0.1 |
Pt215 | 10*10*0.5 | Pt241 | 15*15*0.2 | Pt262 | 30*30*0.2 |
