Медицинская Больничная младенческой новорожденных матрас теплее BN-100A Высший

1. Microprocessor based servo controlled temperature system.

2. The microprocessor-controlled unit allows for three settings: manual or automatic.

3. Alarm functions for safety includes: Power failure, temperature deviation, Temperature sensor failure, over temperature.

4. APGAR timer to record therapy time

5. Convenient X-ray cassette under infant bed

6. Heater head can be adjusted +90 degree horizontally

7. Tilt angle of infant bed is adjustable

8. Transparent protector folded

9. Adopts anti-explosion micro crystal quartz infrared radiation tube for its radiation source, the heating is quick and life-span is long

10. Alarms are audible and visual

11. A second thermal cut-out function for more safety

12. Skin temperature sensor failure protect function avoid over temperature

13. Temperature deviation can be amended in front panel directly

14.RS232

15.2 Infusion seal

1. Power supply: 110/220V 60/50Hz

2. Power input: ≤ 1000VA

3. Operating condition

An ambient Temperature: 18℃-30℃

An ambient Relative Humidity: 30--75 % RH

Atmospheric Pressure: 700~1060 hPa

An ambient Air Velocity <0.3m/s

4. Temperature control: 32~38℃

5. Temperature control accuracy: ≤ 0.5℃

6. Mattress temperature uniformity: <25℃

7. Skin temperature sensor accuracy: + /-0.3℃

8. Warm-up time: ≤ 30min

9. Infant bed tilt angle: + 10 degree

10. APGAR timer range: ≤ 24h

11. Heater head horizontal: 90 degree;

12. Mattress size: 67cm X 54cm

13. Distance from heater to mattress: 80cm

Delivery and storage

Environment Temp: -40--+55℃
Environment Relative Humidity: ≤ 95%
Atmospheric Pressure: 500~1060Hpa

Infusion seal

Side rail

Material of the machine body

Aluminum magnesium fluoride coating

Acid-proof alkali not rust
