Product Description


The all-in-one solution is to integrate the controller, operation interface, input/output, analog input/output, high-speedcounting/pulse and communication port into a compact unit to meet the needs of customer equipment automation control.




Features of product:
1. Motion control function
* Up to 8 high-speed pulses
* Circular and linear interpolation

2. Internet function (optional)
* WiFi module (100m live coverage)
* GPRS module (mobile, universal Unicom signal)
* 4G module (common to mobile, China Unicom, telecommunications)
* RFM module (distance transmission, travel-free)

3. High integration (multiple choice)
* Operation interface * Switch * Analog
* High-speed counting * High speed pulse * Communication port

4. Flexible customization
* Personalized tailor-made machine


Specification


Display
Dimension
200*146*36mm
Cutout size
192*138mm
Power Consumption
6-7W
Feature
60K-color resistive touch screen, supports portrait display
Memory
RAM
NOR Flash 16MB
ROM
64MB
CPU
32bit CPU 408MHz
I/O
DI/DO
Max 24DI/20DO(max 16MR)
DI/DO level
Input: Passive NPN, public terminal isolated
DO type
Relay (MR) or transistor (MT, Y0-Y3 are MOS) or mixed (MRT)
(Relay output: max load 5A/ transistor output: max load 500mA)
Analog I/O
(optional)
Max 12AI/8AO
AI type (optional)
Thermocouple E/E_/K/K_/S/S_/T/T_/J/J_ / PT100/ PT1000/ NTC10K/ NTC50K/ NTC100K/
AO type (optional)
0~10V /0~5V/ 0~20mA/ 4~20mA/ mixed/
-5~5V/ -10~10V (2AO for 1 minus voltage)
High-speed function
High-speed counting
Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz,
or 2 ABZ 60KHz + 1 AB phase 10 KHz
High-speed pulse
8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz.
High-speed counting + high-speed pulse < 480KHz
Connection
HMI
Type-C HMI download port (can download PLC program through the USB penetrating function), RS232 port
1 RS485 (changed from default RS232)
PLC
1 TYPE-C, 1 RS232 (program port)
1 RS485 or 2 RS485 COM ports (RS485 port on HMI and RS232 on PLC will be unavailable)
CAN (2.0A/B) port, Ethernet port, WIFI (will occupy default RS232 port)
Software
HMI
Coolmay mView HMI Programming Software
PLC
Compatible with Mitsubishi GX Developer 8.86 and WORKS 2


Packing & Delivery




Packed by carton box.


Company Profile




Shenzhen Coolmay Technology Co., Ltd mainly develops and manufactures Coolmay brand products, including HMI, PLC, HMI/PLC All-In-One and related modules. Established in 2005, Coolmay has been focusing on providing various products with high quality and competitive price for automatic industries and home automation, based on the belief of "Cooperation, Honesty, Pragmatism, Innovation".
Coolmay HMI/PLC all-in-one, the original and innovative products, integrates PLC, HMI, I/O, analog, which goes very popular in automatic industries. It is convenient and flexible, saving more cost and space than tranditional separate HMI and PLC. And it is used widely in the fields of different machinery, central air-conditional equipment environmental protection projects. OEM and ODM are supported according to customers' requirement.
Coolmay also integrates touch panel, plc with app to provide a powerful intelligent housing system for home automation.


FAQ


1. who are we?
We are based in Guangdong, China, start from 2006,sell to Southeast Asia(20.00%),South Asia(17.00%),Eastern Europe(12.00%),Africa(10.00%),Eastern Asia(8.00%),Domestic Market(7.00%),North America(5.00%),Mid East(5.00%),Western Europe(4.00%),South America(4.00%),Central America(2.00%),Southern Europe(2.00%),Northern Europe(2.00%),Oceania(2.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
HMI PLC All-in-One,PLC controller,HMI touch screen,PLC Programmable Logic Controller

4. why should you buy from us not from other suppliers?
* Supports OEM and ODM
* Easy maintenance with small size, plug and play

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
