Оригинальный производитель полностью автоматическая программа обнаружения BGA S7200 рентгеновское оборудование для проверки FPC

Technology Parameters:

Detail Images

Details

1. Closed Tube from HAMAMATSU Japan.
2. Imported Detector from Korea.
3. Micro-focus.
4. Spot size down to 5µ.
5. 5″ x 5″ or 4″ x 3″ high resolution and ultra-resolution CMOS digital panel detectors.
6. 70° camera tilt for oblique angle viewing.
7. 22″ x 18″ Inspection Stage with 350° Rotation.
8. Color mapping camera with zoom window provides easy location and identification of faults.
9. Z axis movement of the x-ray tube and detector.
10. Computer controlled kV and mA settings.
11. Computer controlled variable speed X-Y stage (and rotate).
12. Simple point and click, intuitive GUI provides access to create advanced inspection routines.
13. All s/w tools standard including (but not limited to).
14. BGA Void detection and automatic calculations.
15. Mobile Flex Cable FPC x-ray inspection.
16. SMT Mounting and PCB X-ray inspection.
17. Easy macro recording for intuitive step and repeat programming.
18. Various measuring tools for TH, radius, area, perimeter, etc.
19. Industrial PC with Windows 7, 24″ LCD flat panel display.

Applications

Standard Configuration

1. Adjust the speed of the stage through the space bar: slow, constant, fast.

2. Keyboard control x, y, Z1 Z2 four axis movement.

3. The user can control the speed of the stage by programming.

Fully Automatic BGA Detection Program

1. Simple mouse click programming to automatically detect each BGA on the component without operator intervention.

2. Automatic BGA detection program can accurately check BGA diameter, cavity proportion area and roundness.

3. Automatic BGA detection program has high repeatability of detection results for process control.

4. The test results will be displayed on the screen and can be output to excel for review and archiving.

CNC Programming

1. Simple mouse click operation to operate detection program.

2. Sample table can be positioned in X, Y direction; X-ray optical tube and detector can be positioned in Z direction.

3. Software set voltage and current.

4. Image settings: brightness, contrast, auto adjustment and exposure.

5. Users can set the pause time for program switching.

6. Anti-collision system can meet the maximum tilt and observation.

Our Service and Advantages

1. Your inquiry will be replied in 12 hours.
2. Original Manufacture to customers, with competitive price.
3. We provide one year warranty, free training and whole life technology support.
4. We can arrange the shipment by air, DHL, Fedex, UPS, and by Sea, etc for you, and will give you the tracking NO. after shipment.

5. Well-trained and professional after-sales service team to support you.
6. Manual and Demo video CD will package with machine. It will show you how to use machine step by step.
7. Payment terms, like T/T, Westerunion, PayPal is choosed by customers.
