371 Hp 10Wheel Tractor Head Truck Rhd Lhd Heavy Trucks And Tractors Head

Product Description

Competitive Advantage:

1) with all kinds of truck model, which can fulfill your requirement

2) the key parts adopt the world's top technology products

3) based on strong technical support and top level technology make the trucks with high quality and more reliable

4) it has higher safety and running efficiency.

5) excellent appearance of cabin, safety, reliable

6) low fuel consumption

7) strong enough engine

8) competitive price, cost-effective

9) quick and efficient spare parts supply bring you more convenient

10) fast delivery time, we can arrange production according to your needs exactly and Quickly

11) professional import and export dealing procedure, make customs clearance more high efficiency

Applications:

It’s suitable for towing all kinds semi trailer which is used in Logistics business, construction site and Mining area.

This model is the proven product of SINITRUK, which features reliable structure, great loading capacity, excellent power from 336-420HP, reliable performance. This model can meet the requirements of different road conditions. This model can satisfy your need of long distance highway transportation.

The fifth version of the highway transport is equipped with iron reinforced frame, Iron shell transmission and two-stage reduction drive axle which can loaded16 ton, single-stage reduction drive axle, which can loaded 16 ton is optional, mainly used for comprehensive road conditions and overloading of the transport conditions.

HOWO 6x4 TRACTOR TRUCK
SPECIFICATION
Engine	Make: SINOTRUK Disel:4-Stroke direct injection diesel engine Engine model:WD615.69,Euro II 6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection Maximum output: 336hp(247KW) at 2200 rpm Maximum torque: 1350Nm at 1100-1600 rpm Displacement:9.726L Bore:126mm Stroke:130mm	Make: SINOTRUK Disel:4-Stroke direct injection diesel engine Engine model:WD615.47,Euro II 6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection Maximum output: 371hp(273KW) at 2200 rpm Maximum torque: 1500Nm at 1100-1600 rpm Displacement:9.726L Bore:126mm Stroke:130mm	Make: SINOTRUK Disel:4-Stroke direct injection diesel engine Engine model:D12.42,Euro II 6-cylinder in line, 4-stroke, water cooled, turbocharged, direct injection Maximum output: 420hp(309KW) at 2000 rpm Maximum torque: 1820Nm at 1100-1500 rpm Displacement:11.596L Bore:126mm Stroke:155mm
Clutch	Single-plate dry coil-spring clutch, diameter 430mm,hydraulically operating with air assistance.
Transmission	HW19712, 12 forward, 2 reverse HW19710, 10 forward, 2 reverse
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle	HF9 Steering with double T-cross section beam
Rear Axles	HC16 Pressed axle housing, central single reduction with planetary wheel reduction and with differential lock
Chassis	Frame: U-profile parallel ladder frame with section of 300×80×8mm and reinforced subframe, all cold riveted cross members
	Aluminum fuel tank: 400 L capacity with locking fuel cap, fitted to the off side of the chassis
Steering	power steering, model 8098,hydraulic steering with power assistance. Ratio: 22.2-26.2
Braking System	Service brake: dual circuit compressed air brake. Parking brake(emergency brake):spring energy, compressed air operating on rear wheels
	Auxiliary brake: engine exhaust valve brake
Tyres	12.00R20, 11pics, radial tyres 315/80R22.5, 295/80R22.5, 12R22.5
Cab	HW76 Cab, one berth, all steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts, adjustable steering wheel, air horn, with 4-point support fully floating suspension + shock absorbers
				Electrical System	Operating voltage:24V,negative grounded
					Starter:24V.7.5Kw
					Alternator:3-phase,28V,1500W
					Batteries:2*12V,165Ah/180Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Instrument	Active check central controller with indicators, with this integral instrument the daily manual checks on the
	vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure
	and battery charging.
Dimensions in mm	Wheel base 3225+1350
	Front wheel track 2022
	Rear wheel track 1830
	Front overhang 1500
	Rear overhang 725
	Approach angle(°) 16
	Departure angel(°) 70
	Overall length 6800
	Overall width 2496
	Overall height 2958
Weight in kg	Dead weight 9200
	Front axle loading capacity 7000
	Rear axle loading capacity 18000/18000
Performance	Maximum driving speed(km/h) 102
	Fuel consumption(L/100km) 30-33
