Пленка тонкие пленки 15 микрон наклейки бумаги офсетная Этикетка печатная

We are creating the first brand of Chinese label machine with all strength.

Electric Control System: The main control unit adopts imported electric component, together with CPU via DOS system to control the servo motors, which ensures the machine , high responding, accurate towing , easy operating and safe running.

Shaftless Driving: The machine uses servo motor to drive the motor directly, provide a guarantee for precise high speed running.

Overprinting system: Once printing length is input at the main control unit, every unit will move automatically to the preset position. Each unit is controlled individually by a motor. With the help of CCD image , lateral longitudinal and bevel direction registration can be achieved without stopping the machine production. This greatly increases the printing quality and reduce the production wastage.

Printing Unit: Each unit can work independently, which enhance the production efficiency greatly . There is a touch screen on each unit, you can work easily .

Water And Ink Control: The machine adopts advanced American water and ink control system which ensures the water and in balance, stability at low and high speed with bright print result. The classic structure , which makes the water and ink perfect mixture and balance on the first printing roller,  which is firstly used in China,  effectively prevent the ink bar and ghost from the print. Film and paper can be printed on this machine easily.

Lubricating System: the machine uses the automatically cycling oil-supply system to ensure the accuracy and service the life of machine.

The computer controlled automatic and manual plate mounting and dismounting system shortened the plate changing time and increase the safety level of the machine(Plate changing for 6 color only needs 6 minutes)

The Japanese origin SMC Pneumatic clutch pressure control system ensure smooth and accurate running of the machine; two clutching done by Japanese Fujikoshi three-point suspension bearing, makes the PS plate and the water blanket fully pre-inked and then be pressed which greatly reduces the pre-print water wastage.

7 o ’ clock arrangement of the printing rollers, high precision servo drive, twice clutching control and color lose prevention system , make high quality prints and competitiveness of the machine.

The new ink fountain partition structure, easier to adjust the ink, reducing printing time and paper waster.

suitable materials:

self-adhesive paper / pvc / pet / opp / polyester film / laminate tubes / flexible packaging material , etc

Thickness of substrate: 60g-350g

suitable ink: UV ink

suitable printing plate: PS plate

1.Integral Rewinder

2.Flat-bed Screen Unit

3.Rotary Stepback Hot-Stamping unit

4.Remote ink control

5.Cold stamping / lamination unit

Packaging Details

Standard export packing by sea and for long distance transportation by truck

Port

Shipping port: Tianjin Port

1.Quotation Validity : 30 days

2.Delivery Time :75 days after the deposit payment received by the seller

3.Country of Origin and manufacturer: HEBEI WANJIE MACHINERY TECHNOLOGY CO.,LTD P.R.CHINA

4.Shipping port: Tianjin Port

5.Payment Terms: 30% advanced T/T, 70% T/T before shipment. Installation costs etc. are not included in the price.

6.Guarantee:12 months starting from the date of signing Acceptance Report for installation and Commissioning.

7.Installation and commissioning in the customer’s factory:

8.The seller’s engineers’ traveling, board and lodging costs and air tickets are for the buyer’s account.
