Tycorun Gel Battery Power Supply MPPT Solar Charge Controller for Solar Energy System 50A 80A 100A
MPPT Solar Charge Controller
It has an efficient MPPT algorithm, MPPT efficiency ≥99.5%，and converter efficiency up to 98%.
Charge mode: three stages (constant current, constant voltage, floating charge), it prolongs service life of the batteries.
Four types of load mode selection: ON/OFF, PV voltage control, Dual Time control, PV+Time control .
Battery system voltage automatic recognition.
Three kinds of commonly used lead-acid battery (Seal\Gel\Flooded) parameter settings fcan be selected by the user, and the user can also customize the parameters for other battery charging.
It has a current limiting charging function. When the power of PV is too large, the controller automatically keeps the charging power, and the charging current will not exceed the rated value.
Support multi - machine parallel to realize system power upgrade.
High definition LCD display function to check the device running data and working status, also can support modify the controller display parameter.
RS485 communication, we can offer communication protocol to convenient user’s integrated management and secondary development.
Support PC software monitoring and WiFi module to realize APP cloud monitoring.
CE, RoHS, FCC certifications approved, we can assist clients to pass various certifications.
3 years warranty
product name
Tycorun Gel Battery Power Supply MPPT Solar Charge Controller for Solar Energy System 50A 80A 100A
Mars series
Mars-48BL-80A
Mars-48BL-100A
Mars-48BH-80A
Mars-96BH-50A
Product category
Controller Properties
MPPT (maximum power point tracking)
MPPT efficiency
≥99.5%
Standby power
0.5W~1.2W
System voltage
Automatic recognition
48V
96V
Heat-dissipating method
Air cooling
Input Characteristics
Max.PV input voltage(VOC)
DC150V
DC300V
Start the charge voltage point
Battery voltage + 3V
Battery voltage + 10V
Low input voltage protection point
Battery voltage + 2V
Battery voltage + 5V
Over voltage protection point
DC150V
DC300V
Rated PV power
12V system
1040W
1300W
－
－
24V system
2080W
2600W
－
－
36V system
3120W
3900W
－
－
48V system
4160W
5200W
4160W
96V system
－
－
－
5200W
Charge Characteristics
Selectable Battery Types (Default Gel battery)
Sealed lead acid, Gel battery, Flooded (Other types of the batteries also can be defined)
8-pin RJ45 port/RS485/support PC software monitoring/ support WiFi module to realize APP cloud monitoring
Other Parameters
Protect function
Input-output over \ under voltage protection, Prevention of connection reverse protection,battery shedding protection etc.
Operation Temperature
-20℃~+50℃
Storage Temperature
-40℃~+75℃
IP(Ingress protection)
IP67
Max. connection size
50mm2
Net Weight (kg)
12.8
Gross Weight (kg)
13
Product Size（mm）
500*350*140
Packing Size(mm)
610*448*265
