CG FL-2C шунта 10A 20A 50A 100A 150A 200A 300A 400A 500A 600A 750A 75mV DC производитель с базой Амперметр токового

Описание и отзывы

Характеристики

CG FL-2C Type 10A 20A 40A 50A 50mV 75mV 100mV Electrical Current DC Shunt Resistor With Base

Current Rating	10-100A
Operating Temperature	-40°C ~+60°C
Voltage Drop	75mV
Accuracy Class	0.5
Material	Copper+Manganin
Overload Capacity	120% Of Rated Current For 2H
Function	Are Used To Multiply The Measuring Range Of Current Of Measuring Instruments.
Application	Use For DC Digital Amp Meter, etc.





Remark:

There are many shunts, but the shape can be customized according to customer‘s requirements.



Q:How and how long can I get a sample to check your quality?

A: After price confirmation, you can require for samples to check our quality. Then after you send us confirmed

    files, the samples will be ready for delivery in 7 days. The samples will be sent to you via express and arrive

    in 5-7 workdays.



Q:How to order our product ?

A: 1).Please tell us the model and quantity and other request you need.

    2).We make the PI for you.

    3).After you confirm the PI, we arrange the order for you after receiving your payment.

    4).After the goods finished, we send the goods out to you and tell you the tracking number.

    5).We will track your goods until you receive the goods.



Q: Can I have a visit to your factory before the order?

A:  Welcome! Our factory address: Fenghuang Industrial Zone,Yueqing City, Wenzhou, Zhejiang, China

     (Mainland)



Q: What's your shipment method?

A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the

     most proper shipment method.



Q: What's about MOQ?

A: First order MOQ=1pcs



Q: If i want to release order, what's the payment method you accept ?

A: We accept T/T, Paypal, Western union, L/C,etc.



Q: If i want to release order, what's the process?

A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
