Лидер продаж продукты MUP отличное качество соединитель micro SIM-карты SMT типа PCB держатель контактный разъем 2
- Категории: Headers & Wire Housings >>>
- Поставщик: Shenzhen,Mup,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Top selling products in alibaba mupc790 SMT Type micro SIM card holder pin header 2 54 connector
General Characteristics | Dimensions | 13.40L*13.40W*2.40H mm |
Weight | Approx 0.40±0.2g | |
Card size | 25.00×15.00×0.76mm | |
Contact principle | Friction technology | |
Mounting System | SMT(Without post) | |
Durability | 5,000 cycles Min. | |
Material | Insulator | Thermoplastic UL94V-0 |
Contact | Phosphor bronze | |
Plating | Gold over nickel | |
Electrical Characteristics | Number of Contacts | 6 Pins ,or 8 Pins |
Contact highly | 0.70±0.20mm | |
Insulation resistance pin to pin | >1000 MΩ/500 VDC | |
Rated voltage | 50V max | |
Rated current | 1A max., 10μA min. | |
Contact resistance | 50 mΩ typical, 100mΩ max. | |
Dielectric withstanding voltage | 500V AC rms 1min.(sea level) | |
Solderability | Vapor phase | 215℃,30sec.Max |
Wave | Not Applicable | |
Manual soldering | 370℃,3sec.Max | |
Environmental Characteristics | Operating temperature | -40℃~ +85℃ |
Operating humidity | 10%~ +95%RH |
Company profile
Company Profile
Manufacturing Line
Product Application
Certification &Exhibition
Delivery
Service
| Price Term | ♦ FOB Shenzhen EXW |
| Payment Terms | ♦ T/T, Paypal |
| Delivery | ♦ UPS, DHL, FEDEX,TNT |
| ♦ Select the most economic and efficient way. | |
| ♦ Sent the tracking number to u after delivery. | |
| Samples | ♦ Free samples will be sent on request. |
| ♦ The samples lead time is within 3-5 days after u confirmed. |
Why choosing us:
1. Almost 20 years of R&D and manufacturing experience in the connector industry.
2. A variety of channels to satisfy various demands including industrial product.
3. Sufficient stock for your urgent demand.
4. Professional high quality service to solve your confusion.
5. Timely reply within 2 hours during working time.
Who we are:
1. Shenzhen MUP INDUSTRIAL CO.,LTD is a reliable and professional connector supplier.
2. We can be No.one in this field.
3. We are with great passion of it.
4. We know, we can gain what we seed.
5. We can surpass our competitors by achieving it.
6. Our customers will trust us and make long-term cooperation with us.
7. Enterprise spirit : Honest &Trustworthy Enterprising Win& win
What we do :
MUP has a number of highly experienced , passion and dedicated professional R & D team, Produce various precision connectors with stable quality , Products widely used in Banking Equipment, Computer Communication, Advertising Machine, Automotive Electronics, Smart Reader, Smart Watch, STB: MUP has established a long-term stable cooperative relations with many well-known enterprises domestic and overseas. To be your reliable and convenient purchasing partner and become the most trusted brand in the industry is our goal.
