Новый дизайн 4K/8MP USB 3 0 модуль камеры Поддержка H.264 для
- Категории: CCTV Lens >>>
- Поставщик: MIDAS,TOUCH,SOLUTIONS,INC.
Поделиться:
Описание и отзывы
Характеристики
Product Description
MCY-3080-A01 not only offers up to 4K resolution (3840X2160) for image applications to take still image, but also offers video stream for end user to preview/record motion image through USB 3.0 interface. MCY-3080-A01 can support UHD (3840×2160) resolution up to 30 fps at MJPG and H.264 mode,MCY-3080 is an USB Video Class (UVC) compliant camera module with video feature, designed for portable notebook PC image applications. It is made up of the following components, CMOS sensor, lens, holder, backend, PCB, image processing circuit and connector, to come out a digital video device. It shall be a reliable device which is embedded in notebook PC to transfer video data through USB interface to notebook PC.MCY-3080 not only offers up to UHD resolution (3840×2160) for image applications to take still image, but also offers video stream for end user to preview/record motion image through USB 3.0 interface. And It can support FHD (1920×1080) resolution up to 30 fps at MJPG mode, UHD (3840×2160) resolution up to 30fps at H.264 mode. MCY-3080 builds in AE, AWB and AGC for automatic image control supported by CMOS sensor. For image quality control, it also offers UVC standardized User Interface (UI) to let end user well tune image by property page.
I/O ports (Front) | ||
Size(LWH/mm) | 38.0 x 38.0 x 32.0±0.2 mm (include PCB Thickeness) | |
PCB Thickeness | 1.0 mm | |
Output Interface | USB 3.0 | |
Image/Video Format | 1x Power On/Off Button | |
HD | 1280x720 | |
FHD | 1920x1080 | |
2K | 2048x1536 | |
2.7K | 2688x1512 | |
QSXGA | 2592x1944 | |
UHD | 3840x2160 | |
Frame Rate | 8.29 M – 30FPS | |
Video Class Compliant | YES | |
LED Indicate | N/A | |
Operating Temperature | -10℃ to +65℃ | |
Power Consumption | ||||||
Min | Type | Max | ||||
Input Supply Voltage | 4.85V | 5V | 5.25V | |||
Un-configured Current | - | - | - | |||
Operating Current | - | - | - | |||
Suspend Current | - | - | - | |||
Backend IC Specification | ||
Type | AIT8589D Backend IC with USB3.0 interface | |
Compatibility | USB Video class Compliant, Microsoft WHQL Certified | |
Support Sensor Size | Support Most popular CMOS sensors | |
OS Supported | Win10, Linux, Android | |
Sensor Specification | ||
Optical format | IMX317 1/2.5-inch 8M CMOS Sensor | |
Active resolution | 3840H×2160V | |
Unit pixel size | 1.62μm x 1.62μm | |
0°C to 40°C (with standard HDD/SSD/SATA‐Slim/DRAM) | ||
Lens Specification | ||
F/No. | 2.2 土 5% | |
Field of View | 120° (Diagonal) 112(H) 75(V) | |
Focus Distance | 50cm | |
Note: All specifications are subject to change without furthur notice.
