Вертикальный Многоступенчатый Насос-усилитель DN100 5 л.с. 7 10 15 20 25 40 50

1. Pump head, impeller, diffuser,  suction and discharge part:

     stainless steel AISI304/316

2.  Shaft:

     stainless steel AISI304/316

3.  Excellent material

    Selected domestic and international famous brand high quality bearing,

    special designed mechanical seal, ensure lower noise and longer operation life.

    Variable materials can be used in pump volute casing, impeller and shaft, so it's

    suitable for different applications.

4. Models Meaning:

65QDLF32-60-2

65: The inlet and outlet flange(mm)

QDLF: Vertial multistage stainless steel centrifugal pump

32: Rated flow rate(m³/h)

60: The pump stages are 6

2: The number of the small impeller
