Горячая Распродажа Малый 380 В 15kw 18.8kva 3 фазы используется комплект бесшумного дизель-Солнечный дизельный электрогенератор set15kw передвижная электростанция цена
- Категории: Diesel Generators >>>
- Поставщик: Fuzhou,Guangling,Electrical,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
hot sale Deutz engine 230v 15kw wind turbine generator 15kw generator power plant
Product Parameters
220/380V,single phase, 50HZ,1500Rpm Ricardo Brand
genset type | rated output | Engine | Alternator | control | ||||||
(Kofo) | (Copy stamford) | |||||||||
KW/KVA | model | model | Comap | |||||||
GF2-22 | 16/20 | N4100DS-30 | 184G | Comap IL3AMF9 | ||||||
(100%COPPER) | ||||||||||
Ats (AISIKAI Brand) SKT2-63A 4P 63A | ||||||||||
Genset SIZE | 2150*890*1230 | |||||||||
Weight | 875kgs | |||||||||
Fuel comsuptions 100%Loading | 4L/H | |||||||||
Base Fuel tank | 8-10hours fuel tank | |||||||||
Engine Data sheet | ||||||||||
Engine model | N4100DS-30 | |||||||||
type | Water cooling,in line,four-stroke,wet liner and direct injection | |||||||||
Bore/Stroke mm | 100×115 | |||||||||
Displancement L | 3.61 | |||||||||
Compression ratio | 0.792361111 | |||||||||
Aspiration | naturally | |||||||||
Rated output kW | 33 | |||||||||
Rated speed r/min | 1500 | |||||||||
Fuel consumption rate g/kW.h | ≤251 | |||||||||
No load Speed r/min | ≤1890 | |||||||||
loadling speed r/min | ≤650 | |||||||||
Piston speed M/s | 11.5 | |||||||||
12 hours fuel consuption g/kW.h | 9.86 | |||||||||
Highest Oil temperature ℃ | 100 | |||||||||
Oil consumption rate g/kW.h | ≤2.04 | |||||||||
Oil sump capacity L | 13 | |||||||||
Starting method | Electric motor start | |||||||||
Lubricating method | Pressure lubrication | |||||||||
Crankshaft rotating direction | Counter clockwise(face to output end) | |||||||||
Fring order | 1-3-4-2 | |||||||||
Net mass kg | 380 | |||||||||
engine size mm | 725×600×725 | |||||||||
Overall dimension | ||||||||||
Alternator data sheet | ||||||||||
Brnad | Copy stamford | |||||||||
model | 184G | |||||||||
Prime power | 16kw | |||||||||
Exciation mode | Brushless self-excitation | |||||||||
Power factor | 0.8-1.0 | |||||||||
Pressure regulating mode | AVR automatic pressure regulation | |||||||||
bearing | Long life and no need maintencances | |||||||||
Class of insulation | H grade | |||||||||
protection | IP23 | |||||||||
Our Services
Guangling strictly adopt the international warranty.
Warranty: Guarantee for one year or 1000 running hours (accord to whichever reach first) from shipment date.
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
During the guarantee period, guangling will provide the free easy-damaged spare parts for problems caused
by our quality of production or raw material, except the damageable spare parts caused by customer's incorrect man-
made operation.
After expiration, Guangling provides cost spare-parts maintenance for gensets .
FAQ
Q1: What is your MOQ of this item?
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
A: 1 pcs
Q2: What is the lead time?
A:2days after receiving your L/C or TT deposit.But if your order is some special engine and alternator, then the delivery time is longer.
Q3: Is it able to make customer's own brand name?
A: We can be your OEM manufacture with your authorization of brand.
Q4: Where is your Loading Port?
A: Any port in China. Usually Fuzhou port.
Q5: What is your payment term?
A: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
Q6: What is your company's available production capacity?
A:1000 000000
For More details,can send us inqury to know Factory Pirce!
