High Compressive Strength rigid Low Density insulation cellular foam glass for building
Product Description
Foam Cellular Glass Insulation Overview
HUAYUE® High Performance Cellular Glass is a kind of new inorganic insulation material with glass as the main raw material, mixed with appropriate amount of foaming agent, foamed by high temperature tunnel kiln, and then processed by annealing and cooling treatment. It has uniform independent closed pore structure.
It completely retains the chemical stability of inorganic glass, has low density, low thermal conductivity, no moisture permeability, no water absorption, no combustion, no mildew, no rat biting, high mechanical strength, easy to process and resistant to all chemical attack except hydrofluoric acid. It contains no ozone depleting propellants, flame resistant additives or binders, without VOC or other volatile substances. It can be applied for pipe and equipment insulation, as well as tank bottom support and thermal isolation.
Specification of Foam Cellular Glass Insulation
ITEM | UNIT | SPEC | ||
Density | kg/m3 | 115-220 | ||
Length | mm | 600 | ||
Width | mm | 470 | ||
Thickness | mm | 30-200 | ||
Standard | - | ASTM C552 | ||
Note: Customized products are available on consult. Pipe shell, Curved plate and bricks are also available. | ||||
Foam Cellular Glass Technical Performance
Test Item | Unit | HYFG120 | Testing Method | |||
Density (±10％ Tolerance) | kg/m3 | 120 | ASTM C303 | |||
Thermal Conductivity | Avg.Value | W/(m·K) (10 °C) | 0.043 | ASTM C177/C518 | ||
Highest Single Value | W/(m·K) (10 °C) | 0.044 | ||||
Compressive Strength | Avg.Value | MPa | 0.8 | ASTM C165 | ||
Compressive | Lowest Single Value | MPa | 0.55 | JC/T 647 Appendix A | ||
Bending Strength.Avg | Mpa | ≥0.32 | ASTM C203 | |||
Water Vapor Permeability | ng/(pa.m.s) | ≤0.007 | ASTM E96 | |||
Moisture Absorption by Vol | Vol% | ≤0.5 | ASTM C240 | |||
Service Temperature | °C | -268～482 | - | |||
Coefficient of Linear Thermal Expansion | 1/K | 9×10-6 | ASTM E228 | |||
Combustibility | Non Combustible (Class A1) | Non Combustible (Class A1) | ASTM E136 | |||
Dimensional Stability | Excellent - does not SHRINK OR SWELL. | - | ||||
Color | Black | - | ||||
Composition | Pure Glass. No Asbestos, Fibers or Binders. | - | ||||
Chemical Resistance | Impervious to common acids and their fumes. | - | ||||
Foam Cellular Glass Distinctive Advantages:
⋅ Low density, low thermal conductivity but high compressive strength.
⋅ No water absorption, no permeability.
⋅ Low thermal expansion coefficient, good dimensional stability, no deformation, no crack.
⋅ Fire resistant, incombustible and corrosion resistant.
⋅ No mildew, no rat bitting, and preventing from insect pest or microorganism.
⋅ Applicable for cryogenic, constant and high temperature.
⋅ Convenient for fabrication and installation.
⋅ No-aging, no deterioration.
⋅ Environmental friendly and recyclable.
⋅ No water absorption, no permeability.
⋅ Low thermal expansion coefficient, good dimensional stability, no deformation, no crack.
⋅ Fire resistant, incombustible and corrosion resistant.
⋅ No mildew, no rat bitting, and preventing from insect pest or microorganism.
⋅ Applicable for cryogenic, constant and high temperature.
⋅ Convenient for fabrication and installation.
⋅ No-aging, no deterioration.
⋅ Environmental friendly and recyclable.
⋅ Excellent acoustical coefficient.
Foam Cellular Glass Insulation Applications:
HUAYUE® High Performance Cellular Glass is commonly applied in insulation projects such as: tank and tank base, pipeline, vessel, equipment, cryogenic ship, circulation and dual temperature system etc. for petroleum, chemical, refrigeration, underground projects, shipbuilding, national defense and residential construction industries. It can be applied in severe environment like: low & cryogenic / hot temperature, underground, outdoors, flammable, wet, and chemical, etc.
Company Profile
Why Choose Us
1. Full series thermal heat insulation products, including cellular glass insulation, rubber foam insulation, glass wool insulation, rock wool insulation, XPS, etc.;
2. Stock sale, place the order and delivery immediately for the regular specification;
3. Top quality in the China thermal heat insulation supplier and manufacturer;
4. Reasonable and competitive price, fast lead time;
5. Deliver customized whole solution package to our customer. Welcome to contact us and visit our company and factories at any time!
Certifications
HUAYUE® Foam Cellular Glass insulation materials has obtained FM and ASTM certification of the US, BS476 part 6 & part 7, CE and ISO14001, ISO9001, OHSAS18001 certificate etc.
Quality Control
Quality Assurance
HUAYUE maintains a stringent system of QC, in all its operation by its professional QC staff. We have 6 quality control engineers and test chemists.
We have our own test laboratory. HUAYUE cellular glass heat insulation has been inspected by HUAYUE's Professional Quality Inspectors.
From each batch of raw materials, mid-products to end insulation materials, whole process would be validated by Huayue's Quality Assurance system. This will assure our customers that all materials have been tested and meet our high standards of quality assurance.
Packaging and Shipping
All products will have been strictly quality checked in house before packing. All products will be well packed before shipping. We accept OEM and ODM.
FAQ
Q: Are you manufacturer or trade company?
A: We are professional manufacturer of thermal insulation material, more than 22 Years.
A: We are professional manufacturer of thermal insulation material, more than 22 Years.
Q: Do you accept sample order?
A: Sample order is acceptable. We can offer free sample, sample can be sent within 1~3 days after freight payment confirmed.
A: Sample order is acceptable. We can offer free sample, sample can be sent within 1~3 days after freight payment confirmed.
A: We are in compliance with CE, BS476, FM, ISO9001, ISO14001, OHSAS18001 certificate etc. Our products have excellent chemical, physical features and stability.
Q: What services can Huayue provide？
A: * Any inquires will be replied within 0-1 hours.
* We are professional manufacturer. Welcome to visit our company and factories at any time!
* Any your idea on the packing we can help you to design and put into production. Customized product is available.
* High quality, reasonable and competitive price, fast lead time.
* All products will have been strictly quality checked in house before packing.
* All products will be well packed before shipping. Sample order prepared, just 3-10 days for arriving at your address.
* Any your idea on the packing we can help you to design and put into production. Customized product is available.
* High quality, reasonable and competitive price, fast lead time.
* All products will have been strictly quality checked in house before packing.
* All products will be well packed before shipping. Sample order prepared, just 3-10 days for arriving at your address.
Q: What is Huayue's inspection process for cellular glass ?
A: Raw Material Inspection - Production Process Inspection - Factory Inspection - Parallel Sample Tracking System.
Q: What’s the delivery time of 1x40HQ container loading order?
A: Within 3-20 days after receipt of prepayment.
