Цена:79 000,00 $ - 85 000,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description


summary
The advantage of precision cutting technology is that the endothermic bottom and the fin are formed in one body, the connection area (connection proportion) is large, there is no interface impedance, the fin is thick, can more effectively use the heat dissipation surface area; In addition, precision cutting technology can cut more heat dissipation area per unit volume (increased by more than 50%). The surface of the radiator fin cut by precision cutting technology will form coarse particles, which can make the contact surface between the radiator fin and the air larger and improve the cooling efficiency. The advantage of precision cutting is that the radiator belongs to the overall cutting molding, the heat sink fin and the heat sink base are combined as one, the heat sink produced by precision cutting technology does not exist the problem of thermal resistance on the interface, and the heat conduction efficiency is very high.


·This machine has a lager and more smooth section.
·Seamless, provide more thermal conductivity.
·Smaller spacing can accomodate more radiators.




Specification


The X axis stroke
1000
mm
The Z axis stroke
500
mm
The size of working table
500*1100
mm
The X-axis velocity
10
m/min
The Z-axis velocity
8
m/min
Maximum length of shovel teeth
1000
mm
Maximum width of shovel teeth
copper150   aluminum300
mm
Maximum thickness of shovel teeth
copper1       aluminum2
mm
Minimum thickness of shovel teeth
0.06
mm
Maximum striding distance of shovel teeth
10
mm
Maximum hight of shovel teeth
copper60    aluminum120
mm
Power of Vacuum pump
5.5
kw
Air Storage tanks
0.6
m³
X/Z Servo motor
Japan YASKAWA
Repeated positioning accuracy
＜0.02
mm
Bearing
Japan NSK
Weight
6000KG
kg
Size of machine
3450*1510*2250
mm


Product packaging




Package
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.


Shipping
For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.
For FCL, we get the container and do container loading by our skillful workers carefully.
For forwarders, we have professional and long-term cooperated forwarders who can handle the shipment smoothly. Also we would like to have seamless cooperation with your forwarder at your convenience.


Certifications




Company Profile








FAQ


1. Q: What is the power supply of the machine? A: The standard power supply in china is 380V, 3P, 50Hz. We also can customized
accordingly. 2. Q: What information should the customer provide to get an accurate quotation from us? A: The customer should
provide the related technical requirements, drawings, pictures, industrial voltage, planned output, etc 3. Q: What is the payment
term A: The payment term is 30% down payment, and 70% before shipment(T/T mode), we also accept other payment term, like L/C, DA,
D/P etc 4. Q: What is the delivery time? A: Normally the delivery time of the machine is 30 days after receive down payment. 5. Q:
What is the warrantee period of the machine? A: The warrantee period is one year since the date of B/L.
