Product Description
Main Features:
1.Maintenance free AC driving motor
2.The low gravity design provide good stablity.
3.With low engergy cost, it can meet the common working time.
4.Three sets braking system: hand brake, foot brake, AC driving regenerative brake
5. It is comfortable with big operate space
6.Hydraulic mechanical safety protection: fast cut off valve, lowering speed valve, locked tilting valve, overloading valve
7.Electric system safety protection: limited tilting speed function at high position, undervoltage protection function, relay fuse assembly,natural cooling and fan cooling
1.Maintenance free AC driving motor
2.The low gravity design provide good stablity.
3.With low engergy cost, it can meet the common working time.
4.Three sets braking system: hand brake, foot brake, AC driving regenerative brake
5. It is comfortable with big operate space
6.Hydraulic mechanical safety protection: fast cut off valve, lowering speed valve, locked tilting valve, overloading valve
7.Electric system safety protection: limited tilting speed function at high position, undervoltage protection function, relay fuse assembly,natural cooling and fan cooling
Specification
Model | BLM-CPD15 | BLM-CPD20 | BLM-CPD30 |
Lifting height | 3000mm | 3000mm | 3000mm |
Loading capacity | 1500kg | 2000kg | 3000kg |
Vehicle quality (including battery) | 2500kg | 2900kg | 4500kg |
Battery quality | 380kg | 400kg | 1000kg |
battery capacity | 130Ah*10 | 140Ah*10 | 385Ah |
Voltage | 60V | 60V | 72V |
Charging voltage | 220V | 220V | 380V |
Charging time | 8-10 hrs | 8-10 hrs | 8-10 hrs |
Full working time | 8 hrs or so | 8 hrs or so | 8-10 hrs |
Maximum speed no load | 11 km/h | 13 km/h | 13km/h |
Maximum speed full load | 9 km/h | 10km/h | 11km/h |
Maximum lifting speed no load | 220 mm/s | 220 mm/s | 320mm/s |
Maximum lifting speed full load | 120 mm/s | 120 mm/s | 180mm/s |
Maximum falling speed no load | 320 mm/s | 320 mm/s | 380mm/s |
Maximum falling speed full load | 350 mm/s | 350 mm/s | 420mm/s |
Maximum slope full load | 10% | 13% | 15% |
Full load maximum hook traction | 10kN | 12kN | 20kN |
Brake | Hydraulic brake | Hydraulic brake | Hydraulic brake |
Loader center | 500mm | 500mm | 500mm |
Mast tilting angle | 8 | 8 | 8 |
Min tuning radius | 2180mm | 2230mm | 2380mm |
Dimensions | 2200*1200*2050mm | 2350*1200*2050mm | 2500*1240*2180mm |
Tyres Front | Inflatable 650-10 | Solid 650-10 | Solid 28*9-15 |
Tyres Rear | Solid 500-8 | Solid 500-8 | Solid 600-9 |
Track front | 1050mm | 1050mm | 1100mm |
Track rear | 935mm | 935mm | 985mm |
Wheelbase | 1350mm | 1450mm | 1600mm |
Fork size | 1000*1220*35mm | 1000*1220*40mm | 1200*1220*45mm |
Driving Motor Power | DC 60V 4kw | AC60V 5kw | DC 72V 10kw |
Lifting Motor Power | DC 60V 3kw | DC 60V 4kw | DC 72V 13.5kw |
