2021 Китай поставка экскаватор для пескоструйных работ

Описание и отзывы

Характеристики



1.15 YEARS FACTORY 2. Support exhibition and factory inspection 3 SGS Verifed Merchant 3.SGS Verifed Merchant 5. Perfect management and sales philosophy 6. High grade production quality control 7. Rational and humanized enterprise management. 8. Guided by the strategic planning of high-end talents, the company focuses on the supporting resources market of small and medium-sized environmental protection engineering ships and equipment, and focuses on the intelligent supporting facilities in the middle and high-end dredging field, so as to provide the best cost-effective services for the customers in the international dredging and environmental protection industry. Committed to the dredging and reclamation field, to help the construction equipment matching and upgrading. 9. Advanced strength and technology reserve; Global Service Location: Africa: Egypt, Nigeria, Kenya, South Africa, Cameroon, Ghana, Kenya, Ethiopia, Madagascar Asia (SE Asia) : Thailand, Malaysia, Philippines, Indonesia, Vietnam, Myanmar Asia (Central Asia) : Kazakhstan, Kyrgyzstan, Uzbekistan Eastern Europe: Ukraine, Russia, France, Romania, Algeria, Latin America: Brazil, Peru, Paraguay, Ecuador, Argentina, Colombia, Chile, Asia (S) : Sri Lanka, Pakistan, India, Bangladesh, North America: Mexico, Middle East: UAE, Saudi Arabia, Turkey,









USA technology Gold Sand Dredger Machine / Cutter Suction Dredger





8 inch cutter suction dredger,10 inch cutter suction dredger,12 inch cutter suction dredger,14inch cutter suction dredger

General Description:

Cutter Suction Dredger is self-propelled or non self-propelled, portable cutter suction dredger. Hull can be dismantled and re-assemble easily with box structure . equipped with horizontal shifting devices, cutter

ladder lifting devices, spud devices, deck crane and so on. Widely used in sand-excavating, river dredging, desilting, reclamation for channels and land, port construction, etc.

Advantage:

Reliable and Efficient

The key component like engine, pump and hydraulic system are adopted the international brand.

Tested in pool before delivery.

 Quality testing for each dredger before delivery to ensure all func

tion working properly.

Services

experienced engineers to guide installing and training

local workers. 24/7 technical support standby. Free spare parts in the

first year, low cost for services.

Dismantled and easy transport.





Ser.	Model	Pump	Dredging	Dimensions	Suction/Discharge	Engine(s)
		Capacity	Depth		Pipe Dia.	Power
1	-CSD200	500m3/hr	1-8m	21*4.8*1.4m	250/200mm	224kw
2	-CSD250	800m3/hr	1-10m	25*5.2*1.6m	300/250mm	336kw
3	-CSD300	1200m3/hr	1-12m	27*5.4*1.6m	350/300mm	559kw
4	-CSD400	2200m3/hr	1-14m	33*6.4*1.8m	400/400mm	746kw
5	-CSD450	3000m3/hr	1.5-15m	38*7.3*2.0m	500/450mm	895kw
6	-CSD500	3500m3/hr	1.5-16m	40*7.8*2.0m	600/500mm	1231kw
7	-CSD550	4500m3/hr	1.5-18m	44*8.8*2.2m	650/550mm	1690kw
8	-CSD600	6000m3/hr	1.5-20m	48*9.0*2.4m	700/600mm	2190kw

1) Cutter head is driven by hydraulic motor; cutter bearing has lubrication seal-in units.

2) The dredge pump is driven by the main diesel engine through the reducing gear box.

3) The shifting winches, cutter ladder and lifting winch are driven by the hydraulic motor

Dredger Pontoon

Name: dredger Pontoon

Pontoon material: Ship steel plate

Structure: Can be dismantle and assemble at working site

Pontoon quantity: two side photons and one main photon





Main Application

1) Mineral Mining(such as gold mining,iron mining,tin mining etc)

2) Excavate sand and stone under water as building materials

3) The engineering Land Reclamation/Beach Restoration
4) Port,Lake,River,Harbor,Channel and Dam Desilting
4) New waterway, harbor basin and Canalization new canal were dug, and agricultural water conservancy channels were built

5) Used for trench excavation of submarine pipelines, tunnels and other hydraulic structures





Cutter Suction Dredgers, characterized by strong geographical environment adaptability, simple structure, easy maintenance, reliable performance, long service life, low costs and large workload (1,000 to 4,000 cubic meters per day) are ideal choice for sand field and river sand mining. It can also be used in salt mining in salt lakes, offshore and river dredging, hard riverbed mining, waterway improvement and development. Dug sand after screening and separation is pure and inclusion-free, which is an ideal choice for the building industry.

Cutter suction dredgers can be installed with ore dressing equipment to extract gold, iron ore and other minerals, featuring a high degree of automation, high extraction accuracy and large processing capacity. It leads the industry both at home and abroad.
